Airtac SAI200 Standard Cylinder SAI200AX105S
The AirTAC SAI200 Standard Cylinder SAI200AX105S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 105mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ200 mm
- Stroke105 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI200 Standard Cylinder SAI200AX105S
The AirTAC SAI200X105-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty automation. Delivering a substantial 15708 N push force at 0.5 MPa, this 200 mm bore actuator handles extreme loads with precision. The 105 mm stroke is well-suited for high-force clamping, pressing, and heavy component lifting.
Built with a SUS420J2 stainless steel rod (material code A), this model offers superior corrosion resistance for harsh industrial environments. It includes a built-in magnet (-S) for direct compatibility with CMSE and DMSE sensor switches, which mount seamlessly into the dual extruded-aluminum barrel grooves. Fluid ports feature a tapered PT thread design for secure, leak-free pneumatic connections.
Airtac SAI200 Standard Cylinder SAI200AX105S Technical Specifications
| Model | Airtac SAI200 Standard Cylinder SAI200AX105S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 105 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI200 Standard Cylinder SAI200AX105S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×105 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI200 Standard Cylinder SAI200AX105S Is Used
Heavy Metal Stamping
Provides the 15708 N push force required to form and stamp thick metal sheets in automated fabrication lines.
Large Mold Clamping
Secures heavy injection molds and large tooling blocks safely during high-pressure industrial casting cycles.
Pallet Lifting
Drives robust lifting mechanisms in automated storage systems, moving heavy loaded pallets with a 105 mm stroke.
Is the Airtac SAI200 Standard Cylinder SAI200AX105S the Right Cylinder?
For applications requiring less than 15080 N of pull force at 0.5 MPa, stepping down to the 160 mm bore variant is recommended to save space and air consumption. Because this is a 105 mm stroke, side-load stress on the rod bearing is minimal, though external guides should still be used to prevent binding in heavy press applications. The standardized ISO 15552 mounting interface guarantees a direct replacement for other profile cylinders of identical dimensions. Note that this standard actuator cannot hold a load if air pressure is lost; for fail-safe dropping prevention, specify the SAIL (air-released lock) or BSAI (bidirectional clamp-lock) variant instead.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI200 Standard Cylinder SAI200AX105S FAQ
At 0.5 MPa, the SAI200X105-S generates a push force of 15708 N and a pull force of 15080 N. At 0.7 MPa, the push force increases to 21991 N.
Yes, the SAI200X105-S is dimensionally interchangeable with any standard ISO 15552 profile cylinder, allowing it to serve as a direct replacement for equivalent 200 mm bore actuators.
