Airtac SAI200 Standard Cylinder SAI200AX145S
The AirTAC Airtac SAI200 Standard Cylinder SAI200AX145S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 145mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke145 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
About the Airtac SAI200 Standard Cylinder SAI200AX145S
The AirTAC SAI200X145-S is a double-acting ISO 15552 profile pneumatic cylinder built for heavy-duty tasks. It generates 15708 N of push force at 0.5 MPa, making it suitable for high-load automation. The 145 mm stroke handles substantial linear movements. Equipped with a -S magnet, it integrates seamlessly with CMSE and DMSE reed switches.
This model features an SUS420J2 stainless steel rod (option A) for enhanced corrosion resistance. It uses PT tapered port threads and includes adjustable air cushions at both ends. As a genuine AirTAC component, it ensures reliable performance in demanding industrial environments.
Airtac SAI200 Standard Cylinder SAI200AX145S Technical Specifications
| Model | Airtac SAI200 Standard Cylinder SAI200AX145S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 145 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI200 Standard Cylinder SAI200AX145S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×145 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI200 Standard Cylinder SAI200AX145S Is Used
Heavy Metal Forming
Ideal for driving large presses or stamping equipment where 15708 N of force is required to shape thick metal components.
Automotive Assembly
Provides the robust linear motion needed for lifting and positioning heavy chassis frames or engine blocks on the production line.
Pallet Handling
Suitable for pushing or lifting fully loaded heavy pallets, utilizing the 145 mm stroke to index materials efficiently.
Is the Airtac SAI200 Standard Cylinder SAI200AX145S the Right Cylinder?
Select this 200 mm bore when 160 mm falls short, as the 160 bore provides 10053 N at 0.5 MPa compared to this model's 15708 N. The 145 mm stroke avoids the extreme side-load risks of longer strokes, but always ensure the load is guided to prevent rod bearing wear. For applications requiring position holding without air pressure, consider the SAIL or BSAI variants. This cylinder is dimensionally interchangeable with other ISO 15552 profile cylinders, matching the 200 mm bore, 145 mm stroke, PT port, and standard mounting accessories.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI200 Standard Cylinder SAI200AX145S FAQ
The SAI200X145-S cylinder delivers a push force of 15708 N and a pull force of 15080 N when operated at 0.5 MPa.
Yes, it is dimensionally interchangeable per ISO 15552 standards. You can replace existing profile cylinders with the same 200 mm bore and 145 mm stroke specifications.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models usually ship in 3-4 days.
Fast Reply
Most inquiries answered within 7-8 hours.
