Airtac SAI50 Standard Cylinder SAI50AX100S
The AirTAC SAI50 Standard Cylinder SAI50AX100S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ50 mm
- Stroke100 mm
- Port sizeG1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI50 Standard Cylinder SAI50AX100S
The AirTAC SAI50X100-S is a double-acting ISO 15552 profile cylinder with a 50mm bore and 100mm stroke. It delivers a push force of 982 N at 0.5 MPa, making it a robust choice for mid-range automation tasks. The extruded aluminum barrel design omits tie rods, providing a clean exterior that is dimensionally interchangeable per ISO 15552 standards.
This specific configuration includes a built-in magnet (-S) for use with CMSE or DMSE reed switches, utilizing the dual sensor grooves machined into both sides of the barrel. Additionally, the piston rod is constructed from SUS420J2 stainless steel (material code A), offering enhanced resistance to corrosion compared to standard carbon steel. Ports feature a PT tapered thread.
Airtac SAI50 Standard Cylinder SAI50AX100S Technical Specifications
| Model | Airtac SAI50 Standard Cylinder SAI50AX100S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI50 Standard Cylinder SAI50AX100S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI50 Standard Cylinder SAI50AX100S Is Used
Material Diversion
Actuates sorting gates on packaging lines with precise 100mm strokes and 982 N of thrust at 0.5 MPa.
Clamping Fixtures
Secures workpieces during machining operations, utilizing the SUS420J2 stainless steel rod for durability.
Press Operations
Drives light assembly presses and joining stations, benefiting from the integrated magnet for end-of-stroke confirmation.
Is the Airtac SAI50 Standard Cylinder SAI50AX100S the Right Cylinder?
If your application requires less force, stepping down to a 40mm bore yields 628 N at 0.5 MPa, while moving up to a 63mm bore provides 1559 N for heavier loads. At a 100mm stroke, side-load stress on the rod bearing is minimal, so standard mounting accessories like an FA flange or LB foot bracket are sufficient without needing external guidance.
Because this is a standard double-acting cylinder, it does not hold position when air pressure is removed. The adjustable air cushions at both ends only decelerate the piston near stroke limits. If your process requires the load to remain locked during a pressure drop, integrate the SAIL variant with an air-released lock or use an external pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI50 Standard Cylinder SAI50AX100S FAQ
At 0.5 MPa, this 50mm bore cylinder provides a push force of 982 N and a pull force of 825 N. At the maximum operating pressure of 1.0 MPa, the theoretical push force reaches 200 kgf.
Yes, the SAI50X100-S is a profile-type cylinder that is dimensionally interchangeable with other ISO 15552 standard cylinders. It uses standard mounting interfaces and a G1/4 port, ensuring easy integration.
