Airtac SAI63 Standard Cylinder SAI63AX1000S
The AirTAC Airtac SAI63 Standard Cylinder SAI63AX1000S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
About the Airtac SAI63 Standard Cylinder SAI63AX1000S
The AirTAC SAI63X1000-S is a double-acting ISO 15552 profile cylinder engineered for long-traverse automation tasks. It provides a robust 1559 N push force at 0.5 MPa, making it well-suited for moving moderate loads across a 1000 mm span. The extruded aluminum barrel design omits tie rods, ensuring a clean exterior that resists mechanical interference.
Configured with an integrated magnet for CMSE or DMSE reed switches, this specific model utilizes SUS420J2 stainless steel for the piston rod (option A) to enhance durability against moisture. It also features PT tapered port threads and adjustable air cushions at both ends to manage deceleration over the extended travel distance.
Airtac SAI63 Standard Cylinder SAI63AX1000S Technical Specifications
| Model | Airtac SAI63 Standard Cylinder SAI63AX1000S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI63 Standard Cylinder SAI63AX1000S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 63 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI63 Standard Cylinder SAI63AX1000S Is Used
Material Transfer Lines
Drives large carriages or transfer shuttles over 1000 mm distances in packaging and material handling workflows.
Long-Stroke Assembly Press
Executes extended reach operations for component seating or press-fitting tasks requiring 1559 N of thrust.
Automated Storage Retrieval
Actuates lifting or traversing mechanisms in automated storage systems where a 1000 mm traverse is necessary.
Is the Airtac SAI63 Standard Cylinder SAI63AX1000S the Right Cylinder?
A 63 mm bore provides 1559 N of push force at 0.5 MPa. If your assembly requires less thrust, stepping down to the 50 mm bore yields 982 N; conversely, upgrading to the 80 mm bore provides 2513 N for heavier payloads. Because this unit features a 1000 mm stroke, side loading is a primary concern. An unsupported rod of this length is highly susceptible to bending under lateral stress; always utilize external guide rails or a dedicated guided cylinder to support the load and prevent premature rod-bearing failure.
This model is dimensionally interchangeable per ISO 15552, serving as a drop-in replacement for other standard profile cylinders. To match this exact configuration, specify the 63 mm bore, 1000 mm stroke, PT G3/8 port, TC trunnion or FA flange mounting, and the -S magnet option. Note that standard air cushions only decelerate the piston near stroke end; they do not hold a load. If pressure is lost, the rod will drift, requiring an external pilot-operated check valve or the SAIL locking variant for true position holding.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI63 Standard Cylinder SAI63AX1000S FAQ
At an operating pressure of 0.5 MPa, this 63 mm bore cylinder generates 1559 N of push force and 1402 N of pull force. At 0.7 MPa, the push force increases to 2182 N.
Yes, the SAI series is built to the ISO 15552 standard, making its mounting interface dimensionally interchangeable with other ISO 15552 profile cylinders. You can use it as a drop-in replacement by matching the 63 mm bore and 1000 mm stroke.
