Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10
The AirTAC SAIJ160 Adjustable Cylinder SAIJ160BX100-10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10
The AirTAC SAIJ160X100-10 is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster, delivering massive thrust for heavy-duty operations. The integrated rear stopper allows you to fine-tune the effective travel down to a 90-100 mm window, providing exact end-position calibration without adding external stops.
This specific configuration features a SUS304 stainless steel rod for superior corrosion resistance and uses PT tapered port threads. The extruded aluminum barrel includes sensor grooves on both sides, though this unit is specified without a magnet. Operating at 30-500 mm/s, it utilizes adjustable air cushions at both ends to decelerate heavy loads smoothly.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10 Technical Specifications
| Model | Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 9425 N | 9425 N |
| 0.7 MPa | 13195 N | — |
| Max (@1.0 MPa) | 1922 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10 Is Used
Heavy Press Tuning
Dial in the exact bottoming position of a large press during initial setup, using the 10 mm adjuster to compensate for tooling tolerances without external shims.
Product Changeover
Quickly shift the end-stop by a few millimeters on a heavy-duty assembly line when switching between product variants, minimizing machine downtime.
Is the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10 the Right Cylinder?
The 10 mm adjustment range is ideal for dialing in precise end stops during machine commissioning or product changeover, avoiding the need to physically swap out a fixed-stroke SAI cylinder. Remember that the rear adjuster functions strictly as a travel stop, not a lock; the cylinder will not hold its load without live air pressure. For load-holding requirements, consider an external pilot-operated check valve or the AirTAC SAIL series.
To replace an ISO 15552 cylinder, match the 160 mm bore, 100 mm nominal stroke, 10 mm adjustment, PT ports, and the SUS304 rod material. Mounting options for this SAIJ series include Basic, FA, LB, TC, FTC, TCM1, and TCM2. Because the 100 mm stroke is relatively short for this large bore, side-load risks are minimal, but the robust 40 mm rod and M36x2 thread handle substantial forces reliably.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10 FAQ
At its maximum rated pressure of 1.0 MPa, it can deliver up to 2050 kgf.
The rear adjusting screw acts as a mechanical stopper that lets you shorten the 100 mm nominal stroke by up to 10 mm, providing a usable travel window of 90-100 mm. This allows for fine-tuning the retract end position during commissioning without changing the cylinder.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
