Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100
The AirTAC SAIJ160 Adjustable Cylinder SAIJ160BX100-100 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100
The AirTAC SAIJ160X100-100 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that creates a 0-100 mm usable travel window. The extruded aluminum barrel includes sensor grooves on both sides for straightforward position feedback.
This SKU uses a SUS304 stainless steel rod (option B) paired with an M36x2 rod thread, offering high corrosion resistance and excellent side-load capacity. The rear adjuster acts strictly as a travel stop to fine-tune end positions at commissioning without adding external stops; it does not hold the load without live air pressure. For position holding, use a SAIL or BSAI series cylinder.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100 Technical Specifications
| Model | Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 9425 N | 9425 N |
| 0.7 MPa | 13195 N | — |
| Max (@1.0 MPa) | 1922 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100 Is Used
Heavy Press Tuning
Dial in the exact 0-100 mm travel window during heavy press commissioning to accommodate varying material thicknesses without mechanical modifications.
Corrosive Environment Actuation
Utilize the SUS304 stainless steel rod and 10053 N pull force for reliable, high-thrust positioning in washdown or chemically exposed manufacturing areas.
Is the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100 the Right Cylinder?
The 100 mm adjustment range is ideal for machinery requiring significant product changeovers, allowing you to dial back the stroke precisely without swapping the cylinder. The PT G3/4 port and M36x2 thread are standard for this bore size.
When replacing an ISO 15552 cylinder, match the 160 mm bore, 100 mm stroke, 100 mm adjustment, PT G3/4 port, and the reduced SAIJ mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2). Because the nominal stroke is 100 mm, a side-load guide is less critical than with longer strokes, but the large 40 mm rod diameter still handles substantial offset loads. This configuration does not include a magnet (-S), so external sensors cannot be used.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100 FAQ
The rear adjuster screw allows you to shorten the effective travel anywhere within a 0-100 mm window from the nominal 100 mm stroke. It acts as a mechanical stop to set the end position and does not lock the load without continuous air pressure.
At 0.7 MPa, the push force increases to 14074 N. The cylinder operates efficiently at speeds between 30-500 mm/s.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Related AirTAC SAI Cylinders
Request a Quote for Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-100
Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.
