Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10S
The AirTAC SAIJ160 Adjustable Cylinder SAIJ160BX100-10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10S
The AirTAC SAIJ160X100-10-S is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster, enabling a usable travel window of 90 to 100 mm. It delivers substantial thrust, pushing with 14074 N and pulling with 9425 N at a 0.7 MPa operating pressure. This bore size carries a 40 mm diameter piston rod with an M36x2 thread, providing high rigidity for heavy loads.
This variant includes a SUS304 stainless steel rod (option B) for superior corrosion resistance and features a built-in magnet (-S) for use with AirTAC CMSE reed and DMSE electronic sensors. The extruded aluminum barrel includes sensor grooves on three sides, and the PT tapered port threads ensure a tight, reliable pneumatic connection.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10S Technical Specifications
| Model | Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 9425 N | 9425 N |
| 0.7 MPa | 13195 N | — |
| Max (@1.0 MPa) | 1922 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10S Is Used
Heavy Press Tuning
Dial in the exact 90-100 mm end position during heavy press commissioning to accommodate material thickness variations without swapping cylinders.
Product Changeover
Adjust the retract stop on the fly during a packaging line product changeover, utilizing the 40 mm rod rigidity to handle significant side loads.
Corrosive Assembly Lines
Leverage the SUS304 stainless steel rod in washdown or corrosive manufacturing environments while tracking position via DMSE solid-state sensors.
Is the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10S the Right Cylinder?
Choose this 160 mm bore when a 100 mm nominal stroke requires exact end-position tuning at commissioning without adding external stops. Remember that the rear adjuster acts only as a travel stop; it does not hold the load without live air pressure. For load-holding requirements, consider an AirTAC SAIL or BSAI series cylinder.
When replacing an ISO 15552 cylinder, match the 160 mm bore, 100 mm stroke, 10 mm adjustment range, PT port threads, and the -S magnet requirement. The SAIJ supports mounting options including Basic, FA, LB, TC, FTC, TCM1, and TCM2.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-10S FAQ
The rear adjuster screw allows you to shorten the effective stroke by up to 10 mm, creating a 90 to 100 mm usable travel window. It acts as a physical stop to fine-tune the end position during setup.
