Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-50S
The AirTAC SAIJ160 Adjustable Cylinder SAIJ160BX100-50S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-50S
Its SUS304 stainless steel rod provides excellent corrosion resistance for demanding environments. Fitted with a magnet, it supports CMSE reed and DMSE electronic sensors housed within the dual-side extruded aluminum barrel grooves.
This model features a 100mm nominal stroke paired with a 50mm adjustment range, yielding a highly flexible 50-100mm usable travel window. You can fine-tune the retract end-position at commissioning without external stops. The rear screw acts purely as a travel stop and works alongside the 50mm variable air cushions to decelerate the load, but it does not hold the load without live air pressure.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-50S Technical Specifications
| Model | Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-50S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 9425 N | 9425 N |
| 0.7 MPa | 13195 N | — |
| Max (@1.0 MPa) | 1922 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-50S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-50S Is Used
Machine Changeover
Dial in the 50-100mm travel window during product size changeovers to set new retract positions without swapping hardware.
Assembly Station Setup
Establish precise retract limits during initial commissioning using the rear adjuster and DMSE electronic sensors.
Is the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-50S the Right Cylinder?
Because this is an adjustable-stroke model, it is ideal for machine setups requiring a variable end-stop within the 50-100mm window, rather than committing to a fixed-stroke SAI cylinder.
For an exact ISO 15552 replacement match, ensure your specifications align with this SKU's attributes: 160mm bore, 100mm nominal stroke, 50mm adjustment, PT tapered port threads, and the -S magnet option. Note that the SAIJ mounting set includes Basic, FA, LB, TC, FTC, TCM1, and TCM2, omitting FB, CA, CB, and CR. Since the stroke is 100mm, side-load risks are minimal, but the robust 40mm rod and M36x2 thread handle high axial stresses effectively. If your process requires true load-holding without continuous air pressure, consider the SAIL or BSAI series instead.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX100-50S FAQ
The rear adjuster screw lets you trim the effective stroke within a 50-100mm travel window from the 100mm nominal stroke. It functions as a mechanical stop to set the end position and does not lock the load without live air pressure.
At 0.9 MPa, the push force increases to 18095N.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
