Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S
The AirTAC SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S
The AirTAC SAIJ160X1000-10-S is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster, providing a usable travel window of 990 to 1000 mm. It belongs to the 160 mm bore class, generating 10053 N of pull force at 0.5 MPa and reaching a maximum of 2050 kgf at 1.0 MPa. This made-to-order variant features a SUS304 stainless steel rod and a built-in magnet for position sensing.
Instead of relying on fixed stops, the rear adjustment screw allows you to fine-tune the end position by up to 10 mm during commissioning. The cylinder uses PT tapered ports and operates at speeds between 30 and 500 mm/s. It is dimensionally interchangeable per ISO 15552 and utilizes an extruded aluminum barrel rather than a tie-rod design.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S Technical Specifications
| Model | Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 9425 N | 9425 N |
| 0.7 MPa | 13195 N | — |
| Max (@1.0 MPa) | 1922 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S Is Used
Long-Stroke Machining
Dials in the exact 990 to 1000 mm end-stop for large parts, ensuring precise clamping without repositioning heavy fixtures.
Product Changeover
Adjusts the travel end on automated lines to accommodate different pallet sizes quickly during production shifts.
Assembly Line Setup
Provides a 10 mm tuning window at commissioning to perfectly seat large components without adding external stopper blocks.
Is the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S the Right Cylinder?
Select this adjustable-stroke model when an installation requires precise end-position tuning without swapping out the entire cylinder. If your application needs less thrust, stepping down to a 125 mm bore yields 5734 N of pull force at 0.5 MPa. Conversely, moving up to a 200 mm bore provides 15080 N. Because the nominal stroke is 1000 mm, an external guide is strongly recommended to manage side loads on the extended rod.
The rear adjuster functions strictly as a travel stop and does not hold the load without live air pressure. For load-holding requirements, consider the SAIL or BSAI series. To match this SKU exactly for an ISO 15552 replacement, specify the 160 mm bore, 1000 mm stroke, 10 mm adjustment, PT ports, SUS304 rod, and the -S magnet for CMSE and DMSE sensors. Mounting options are limited to Basic, FA, LB, TC, FTC, TCM1, and TCM2.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-10S FAQ
It reaches a maximum thrust of 2050 kgf at 1.0 MPa.
The rear adjuster acts as a stopper that trims the effective travel back by up to 10 mm, creating a 990 to 1000 mm usable window. It only sets the end position and does not lock the load without live air.
