Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S
The AirTAC SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S
The AirTAC SAIJ160X1000-20-S is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster, delivering massive thrust up to 18095N at 0.9 MPa. Its 1000 mm nominal stroke incorporates a 20 mm adjustment range, yielding a precise 980-1000 mm usable travel window for fine-tuning the retract end position without adding external stops. This made-to-order configuration features a SUS304 stainless steel rod for superior corrosion resistance and includes a magnet for position sensing.
Designed for heavy-duty applications, this bore 160 unit operates at 30-500 mm/s and uses G3/4 PT tapered ports. The extruded aluminum barrel includes sensor grooves on both sides, seamlessly supporting AirTAC CMSE reed and DMSE electronic solid-state switches. The robust 40 mm rod and M36x2 thread provide excellent structural integrity, while the rear adjuster functions strictly as a travel stop to set deceleration, not as a lock to hold loads without live air pressure.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S Technical Specifications
| Model | Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 9425 N | 9425 N |
| 0.7 MPa | 13195 N | — |
| Max (@1.0 MPa) | 1922 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S Is Used
Heavy Machinery Setup
Dial in the exact 980-1000 mm retract position during large equipment commissioning, compensating for mechanical tolerances without machining new hard stops.
Product Size Changeover
Quickly adjust the end-of-stroke position on a conveyor divert arm to accommodate different pallet sizes, utilizing the 20 mm trim range for rapid line format changes.
Is the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S the Right Cylinder?
Select this specific adjustable-stroke model when an application demands exact end-position tuning during commissioning or product changeover, avoiding the need to swap out the entire cylinder. Because this cylinder features a 1000 mm stroke, an external guide is strongly recommended to manage side loads and prevent rod binding over such a long unsupported distance.
When matching ISO 15552 interchangeable replacements, verify the 160 mm bore, 1000 mm stroke, 20 mm adjustment code, G3/4 PT ports, and the -S magnet. For applications requiring true load-holding without continuous live air, note that this cylinder's rear screw and air cushions only decelerate the travel end; a SAIL pneumatic lock, BSAI clamp-lock, or external rod lock is necessary for secure holding.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-20S FAQ
The rear adjusting screw acts as a mechanical stopper, allowing you to shorten the effective stroke by up to 20 mm. This creates a usable travel window of 980 to 1000 mm, enabling fine end-position tuning at commissioning without replacing the cylinder.
