AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-50

The AirTAC SAIJ50 Adjustable Cylinder SAIJ50X100-50 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ50 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 30 mm
$88.16 $95.66Save 7% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ50 stroke, mounting and version on one page All SAIJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-50

The AirTAC SAIJ50X100-50 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster. It provides a usable travel window of 50 to 100 mm, allowing you to dial back the nominal 100 mm stroke by up to 50 mm. The extruded aluminum barrel includes sensor grooves on both sides for straightforward position feedback.

The rear adjustment screw acts purely as a mechanical stop to fine-tune the end position during commissioning or product changeover without swapping the cylinder. It is not a locking device and will not hold the load without live air pressure. This model uses a carbon steel rod with PT tapered port threads, and relies on adjustable air cushions at both ends to decelerate the moving piston smoothly.

Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-50 Technical Specifications

ModelAirtac SAIJ50 Adjustable Cylinder SAIJ50X100-50
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ50 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-50

SAIISO 15552 profile-barrel cylinder series.
50Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-50 Is Used

tune

Machine Changeover

Dial in the exact end-stop position during product size changeovers without replacing the entire cylinder or adding external stopper blocks.

precision_manufacturing

Variable End Positioning

Achieve precise end-of-stroke tuning within the 50-100 mm travel window for multi-format production lines and flexible tooling.

Is the Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-50 the Right Cylinder?

An adjustable stroke is ideal for applications requiring variable end stops or frequent machine setup changes, whereas a fixed-stroke SAI cylinder suits dedicated single-purpose tasks. If your process demands true load-holding without continuous air pressure, consider the SAIL or BSAI series instead of relying on the SAIJ adjuster.

For any stroke length of 300 mm or more, an external guide is recommended to handle side loads and prevent rod damage. This SAIJ model uses a PT tapered port thread and supports mounting options including Basic, FA, LB, TC, FTC, TCM1, and TCM2. It omits the FB, CA, CB, and CR mounts, and is dimensionally interchangeable with ISO 15552 cylinders without claiming direct brand equivalence.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-50 FAQ

At the maximum pressure of 1.0 MPa, it delivers up to 200 kgf.

The rear adjuster screw acts as a mechanical stop that lets you shorten the effective stroke from the nominal 100 mm down to 50 mm, creating a 50-100 mm usable travel window. It sets the end position but does not lock or hold the load without live air pressure.
