AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-75

The AirTAC SAIJ50 Adjustable Cylinder SAIJ50X100-75 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ50 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 30 mm
$88.16 $95.66Save 7% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ50 stroke, mounting and version on one page All SAIJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-75

The AirTAC SAIJ50X100-75 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that allows you to trim the effective travel. With a 100 mm nominal stroke and a 75 mm adjustment range, this model provides a highly versatile 25-100 mm usable travel window.

The rear adjuster acts as a mechanical stop to fine-tune the end position at commissioning without adding external stops. It uses a PT tapered port thread and incorporates variable air cushions at both ends to decelerate the load. The extruded aluminum barrel includes sensor grooves on both sides, ready for CMSE reed or DMSE electronic sensors if a magnet is specified later.

Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-75 Technical Specifications

ModelAirtac SAIJ50 Adjustable Cylinder SAIJ50X100-75
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ50 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-75

SAIISO 15552 profile-barrel cylinder series.
50Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-75 Is Used

settings_input_component

Variable End-Stop Positioning

Dial in the exact retract distance between 25 and 100 mm during machine commissioning to accommodate multiple product sizes without changing cylinders.

tune

Product Changeover

Rapidly adjust the effective stroke on the line when switching to a new package size, using the rear stopper to fine-tune the end position.

Is the Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-75 the Right Cylinder?

If your setup demands less force, stepping down to a 40 mm bore yields 628 N, while moving up to a 63 mm bore provides 1559 N. The 75 mm adjustment range is ideal for product-size changeovers, letting you dial back the stroke dynamically rather than swapping to a fixed-stroke SAI cylinder.

Remember that the rear adjuster and air cushions function as travel stops and deceleration devices, not as locks. A plain SAIJ cylinder will not hold a load without live air pressure, so for fail-safe load holding, consider an SAIL or BSAI cylinder. This SKU uses PT port threads, omits FB, CA, CB, and CR mounting options, and supports Basic, FA, LB, TC, FTC, TCM1, and TCM2 mounts.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ50 Adjustable Cylinder SAIJ50X100-75 FAQ

The rear adjuster screw lets you shorten the 100 mm nominal stroke by up to 75 mm, creating a usable travel window of 25 to 100 mm. This allows precise end-position tuning without swapping the cylinder.
