AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-100S

The AirTAC SAIJ50 Adjustable Cylinder SAIJ50X1000-100S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 1000mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ50 mm
  • Stroke1000 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 30 mm
$198.17 $205.67Save 3% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ50 stroke, mounting and version on one page All SAIJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-100S

The AirTAC SAIJ50X1000-100-S is a double-acting, double-rod ISO 15552 profile cylinder equipped with a rear stroke adjuster. The built-in rear stopper provides a 900-1000mm usable travel window, allowing you to dial back the 1000mm nominal stroke by up to 100mm during commissioning without adding external stops.

This variant includes a standard magnet for position sensing using AirTAC CMSE reed or DMSE electronic sensors fitted into the dual-side barrel grooves. It uses a PT tapered G1/4 port and carbon steel rod. The extruded aluminum profile body omits the FB, CA, CB, and CR mounting options, utilizing a reduced interface set of Basic, FA, LB, TC, FTC, TCM1, and TCM2 brackets.

Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-100S Technical Specifications

ModelAirtac SAIJ50 Adjustable Cylinder SAIJ50X1000-100S
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ50 mm
Stroke1000 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-100S

SAIISO 15552 profile-barrel cylinder series.
50Bore size in mm.
×1000Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-100S Is Used

tune

Variable End-Stop Tuning

Dial in the exact 900-1000mm retract position during machine setup to accommodate varying product lengths without swapping out the entire cylinder.

conveyor_belt

Product Changeover Systems

Quickly adjust the stroke stopper on packaging or conveyor diverters when switching between different package sizes on the same production line.

precision_manufacturing

Long-Stroke Assembly Presses

Fine-tune the end-of-travel position on long-stroke assembly stations to compensate for mechanical wear or varying material stack heights.

Is the Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-100S the Right Cylinder?

Choose this 50mm bore adjustable-stroke cylinder when you need variable end positions for product changeovers rather than a fixed-stroke SAI model. If your application requires less thrust, the 40mm bore offers 628N at 0.5MPa; for heavier loads, the 63mm bore provides 1559N. Because the 1000mm stroke is long, an external guide is recommended to prevent excessive side-loading on the M16x1.5 rod.

Remember that the rear adjuster acts only as a travel stop and the air cushions only manage deceleration; neither will hold the load safely without live air pressure. For true drop-prevention or load-holding without continuous pressure, consider the SAIL pneumatic lock, the BSAI clamp-lock, or an external pilot-operated check valve. To match this ISO 15552 footprint, specify the 50mm bore, 1000mm stroke, 100mm adjustment, PT G1/4 port, and the -S magnet option.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-100S FAQ

The rear adjusting screw acts as an external stopper that lets you shorten the effective stroke by up to 100mm. This creates a 900-1000mm usable travel window, allowing fine-tuning of the end position at commissioning without changing the cylinder itself.

At the maximum 1.0MPa operating pressure, the push force reaches 1767N.
