The AirTAC SAIJ50 Adjustable Cylinder SAIJ50X1000-50 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 1000mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SAIJ50X1000-50 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that allows you to fine-tune the effective travel down to a 950-1000 mm window. The extruded aluminum barrel includes sensor grooves on both sides for flexible mounting of CMSE or DMSE switches.
Because the nominal 1000 mm stroke is substantial, the 16 mm carbon steel rod and M12x1.25 thread provide necessary rigidity, though an external guide is strongly recommended for unsupported loads of this length. The rear adjuster acts purely as a travel stop for commissioning and product changeovers, meaning it will not hold the load without live air pressure.
| Model | Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-50 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 50 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Dial in the 950-1000 mm retract stop to accommodate different package lengths on a sorting line without changing out the actuator hardware.
Fine-tune the end-of-stroke position during product family transitions, using the 50 mm rear screw to establish a new datum point quickly.
Drive large components over a 1000 mm span while retaining the ability to adjust the final clamping position by up to 50 mm during commissioning.
The 50 mm adjustment range is specifically useful for machines that process varying product sizes, allowing you to dial in the exact end position without swapping the cylinder or adding external mechanical stops.
When replacing an ISO 15552 cylinder, match the 50 mm bore, 1000 mm stroke, PT tapered port thread, and the reduced SAIJ mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2). For load-holding without live pressure, select a SAIL (air-released lock) or BSAI (clamp-lock) cylinder instead, as this adjuster is not a brake. At 1000 mm, side-load forces are amplified; always use a dedicated external guide to prevent rod bending.
Quick checklist
The rear adjuster screw lets you shorten the nominal 1000 mm stroke by up to 50 mm, creating a usable travel window of 950-1000 mm. It functions as a mechanical stop for end-position tuning and does not lock the load without live air pressure.
It can deliver up to 1767 N at 0.9 MPa.
