Airtac SC40 Standard Cylinder SC40X10
The AirTAC Airtac SC40 Standard Cylinder SC40X10 is a genuine double-acting standard air cylinder with a Ø40mm bore and 10mm stroke, PT1/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ40 mm
- Stroke10 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM12×1.25
- CushionAdjustable, 21 mm
About the Airtac SC40 Standard Cylinder SC40X10
The AirTAC SC40X10 is a compact double-acting tie-rod cylinder delivering 628 N of push force at 0.5 MPa (1130 N at 0.9 MPa). With a 40 mm bore and a short 10 mm stroke, it is ideal for clamping, ejecting, and sorting tasks where space is tight and cycle speed is critical.
This model features a 16 mm diameter piston rod, PT1/4 ports, and a 21 mm adjustable air cushion to decelerate the piston smoothly. The total extended body length is approximately 152 mm (142 mm body length A + 10 mm stroke). Standard TPU seals provide a reliable operating range of -20 to +70 °C.
Airtac SC40 Standard Cylinder SC40X10 Technical Specifications
| Model | Airtac SC40 Standard Cylinder SC40X10 |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø40 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | — |
| Max (approx.) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC40 Standard Cylinder SC40X10
| SC | Standard tie-rod cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC40 Standard Cylinder SC40X10 Is Used
Short-Stroke Clamping
The 10 mm stroke and 628 N force at 0.5 MPa make it perfect for compact pneumatic clamps and fixtures in assembly jigs.
Part Ejection
Fast-acting ejection of small components from dies or conveyors, leveraging the cylinder's high cycle-rate capability.
Sorting Gates
Operates small diverter gates on packaging lines, where a short, decisive push stroke is needed to redirect products.
Is the Airtac SC40 Standard Cylinder SC40X10 the Right Cylinder?
For applications requiring a compact 10 mm stroke, the SC40X10 provides a robust 628 N at 0.5 MPa. If your force requirement is lower, consider stepping down to the SC32 series (402 N at 0.5 MPa). For higher force in the same stroke, the SC50 delivers 982 N.
When replacing an existing cylinder, ensure a 5-point match: 40 mm bore, 10 mm stroke, PT1/4 port thread, basic (no) mounting accessory, and no built-in magnet. The SC is a tie-rod cylinder and is not dimensionally interchangeable with ISO 15552 profile cylinders.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC40 Standard Cylinder SC40X10 FAQ
At 0.7 MPa operating pressure, the SC40X10 cylinder produces a push force of 879 N. The maximum push force at the 0.9 MPa operating limit is 1130 N.
This specific SC40X10 model does not include the -S magnet option, so standard CMSG/DMSG sensors cannot be used. To use sensors, order the SC40X10-S variant, which includes a built-in magnet on the piston.
