Airtac SC50 Standard Cylinder SC50X100G
The AirTAC SC50 Standard Cylinder SC50X100G is a genuine double-acting standard air cylinder with a Ø50mm bore and 100mm stroke, PT1/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ50 mm
- Stroke100 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 21 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SC50 Standard Cylinder SC50X100G
The SC50X100G is a double-acting tie-rod cylinder delivering 982 N of push force at 0.5 MPa and up to 1767 N at 0.9 MPa operating pressure. Its 20 mm diameter piston rod and 21 mm adjustable air cushion provide reliable deceleration for mid-range automation tasks.
This model features a G1/4 (BSP parallel) port thread, making it suitable for systems standardized on G-type fittings. With a body length of 150 mm and a 100 mm stroke, the total extended length reaches 250 mm, fitting compact machine layouts where a genuine AirTAC actuator is specified.
Airtac SC50 Standard Cylinder SC50X100G Technical Specifications
| Model | Airtac SC50 Standard Cylinder SC50X100G |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø50 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (approx.) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC50 Standard Cylinder SC50X100G
| SC | Standard tie-rod cylinder series. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC50 Standard Cylinder SC50X100G Is Used
Part Rejection Gates
The 100 mm stroke and 982 N push force at 0.5 MPa reliably actuates diverter gates on packaging conveyors, pushing non-conforming products into reject bins with crisp, repeatable motion.
Clamping & Fixturing
With 1767 N of clamping force available at 0.9 MPa, this cylinder secures workpieces on CNC fixtures and welding jigs, holding parts rigidly during machining or assembly operations.
Press-Fit Assembly
The 20 mm rod and tie-rod construction handle the repetitive impact of pressing bushings or bearings into housings, where the adjustable cushion softens end-of-stroke shock for longer seal life.
Is the Airtac SC50 Standard Cylinder SC50X100G the Right Cylinder?
Choose the SC50X100G for applications needing up to 982 N at standard plant pressure. If your load exceeds this, stepping up to the SC63 bore provides 1559 N at 0.5 MPa, while stepping down to SC40 offers 628 N for lighter, faster moves. The 100 mm stroke is well within the 1200 mm maximum standard stroke for this bore, ensuring off-the-shelf availability.
For replacement, match five key points: 50 mm bore, 100 mm stroke, G thread port, basic mounting (no bracket), and no magnet. This cylinder is not dimensionally interchangeable with ISO 15552 profiles; it is a tie-rod design specific to the AirTAC SC family.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC50 Standard Cylinder SC50X100G FAQ
At 0.5 MPa, push force is 982 N and pull force is 825 N. At 0.7 MPa, push reaches 1374 N. The maximum operating force at 0.9 MPa is 1767 N push. Theoretical force at 1.0 MPa is 200 kgf, but the maximum operating pressure is 1.0 MPa.
No. The SC series is a tie-rod cylinder and is shorter than an ISO 15552 cylinder, so mounting dimensions and body length differ. It directly replaces another AirTAC SC50 cylinder with the same bore, stroke, G thread, and basic mounting configuration.
