Airtac SDA Ultra Thin Cylinder SDA40X25-S-B-H

The AirTAC SDA Ultra Thin Cylinder SDA40X25-S-B-H is a genuine double-acting COMPACT (thin) air cylinder with a Ø40mm bore and 25mm stroke, PT1/8 air ports and a riveted short body that saves mounting depth. Sensor slots around the body accept magnetic switches for position sensing.

  • BoreØ40 mm
  • Stroke25 mm
  • Port sizePT1/8
  • Acting typeDouble acting
  • Rod threadM8×1.25 (F) / M14×1.5 (B)
  • CushionFixed NBR bumper (both ends)
$45.20 $52.70Save 14% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDA40 stroke, mounting and version on one page All SDA40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDA Ultra Thin Cylinder SDA40X25-S-B-H

The AirTAC SDA40X25-S-B-H is a double-acting single-rod compact cylinder engineered for tight axial spaces. It delivers a push force of 628.3 N and a pull force of 527.8 N at 0.5 MPa. The short riveted body integrates the barrel, rear cover, piston, and rod, saving valuable mounting depth where a conventional round-body unit cannot fit. This specific configuration includes a male M14x1.5 piston rod thread, a built-in magnet for position sensing, and high-temperature fluororubber (FKM) seals.

The bore inner wall is hard-anodized for durability, and the piston relies on a two-way seal. Instead of an adjustable air cushion, the ends feature a fixed NBR bumper to decelerate the stroke. Grooves around the body accept AirTAC magnetic reed or electronic switches, enabled by the integrated piston magnet. Operating speed ranges from 30-500 mm/s.

Airtac SDA Ultra Thin Cylinder SDA40X25-S-B-H Technical Specifications

ModelAirtac SDA Ultra Thin Cylinder SDA40X25-S-B-H
SeriesSDA compact (thin) cylinder
Bore sizeØ40 mm
Stroke25 mm
Acting typeDouble acting
Port sizePT1/8
Rod end threadM8×1.25 female / M14×1.5 male (B)
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)
Max standard strokeUp to 120 mm

Specifications follow the official AirTAC SDA compact-cylinder datasheet. Confirm against the product label before installation. Port thread: PT (standard). Rod: female thread (blank) / male thread (B).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SDA Ultra Thin Cylinder SDA40X25-S-B-H

SDACompact (thin) double-acting cylinder series.
40Bore size in mm.
×25Stroke length in mm.
SBuilt-in magnet for magnetic-switch position sensing (omit = no magnet).
BMale-thread piston rod (omit = female-thread rod).

Thread: PT standard. Related SDA-family variants: SSA (single-acting push), STA (single-acting pull), SDAD (double rod), SDAJ (adjustable stroke), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDA Ultra Thin Cylinder SDA40X25-S-B-H Is Used

precision_manufacturing

CNC Fixture Clamping

Secures aluminum engine blocks during machining using the 628.3 N extend force, while the male M14x1.5 rod threads directly into custom tooling clamps.

packaging

Palletizing Box Pushers

Diverts corrugated cartons on a packaging line where the short riveted body prevents interference with conveyor guide rails.

straighten

Bending Press Ejection

Ejects formed sheet metal brackets from a hydraulic press, utilizing the FKM seals to withstand elevated ambient heat and airborne oil mist.

Is the Airtac SDA Ultra Thin Cylinder SDA40X25-S-B-H the Right Cylinder?

When sizing this 40mm bore, consider stepping down to the SDA32 which yields 402.1 N of push force at 0.5 MPa, or stepping up to the SDA50 which provides 981.7 N at the same pressure. Be aware that a plain compact cylinder does not hold its load if air pressure is lost or the valve is centered; the piston will drift. For vertical or suspended loads, install an external rod lock or a pilot-operated check valve.

Confirm your ordering essentials: 40mm bore, 25mm stroke, PT1/8 port, male M14x1.5 rod thread (-B), piston magnet (-S), and FKM seals (-H). Because the fixed NBR bumper is not an adjustable cushion, high-energy cycles require an external shock absorber or a slowed approach speed.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Short-body depth vs. a round-body cylinder
  • ✓ Port/thread type (PT)
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
  • ✓ Side load — avoid on a compact rod
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the short piston rod.
  • check Very long strokes are unsuitable for the compact body.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDA Ultra Thin Cylinder SDA40X25-S-B-H FAQ

At 0.5 MPa, the push force is 628.3 N and the pull force is 527.8 N. At 0.7 MPa, push is 879.6 N and pull is 738.9 N. The theoretical maximum push force is 128 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa, with a speed range of 30-500 mm/s.

No to both. The piston drifts if air is lost or the valve centers, so an external rod lock or pilot-operated check valve is required for holding loads. Additionally, it uses a fixed NBR bumper to decelerate at stroke end, not an adjustable air cushion; high speeds require external shock absorption.
