AirTAC SDA Series · Compact Cylinder

Airtac SDA Ultra Thin Cylinder SDA40X30-S-B-H

The AirTAC SDA Ultra Thin Cylinder SDA40X30-S-B-H is a genuine double-acting COMPACT (thin) air cylinder with a Ø40mm bore and 30mm stroke, PT1/8 air ports and a riveted short body that saves mounting depth. Sensor slots around the body accept magnetic switches for position sensing.

  • BoreØ40 mm
  • Stroke30 mm
  • Port sizePT1/8
  • Acting typeDouble acting
  • Rod threadM8×1.25 (F) / M14×1.5 (B)
  • CushionFixed NBR bumper (both ends)
$46.23 $53.73Save 13% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDA40 stroke, mounting and version on one page All SDA40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDA Ultra Thin Cylinder SDA40X30-S-B-H

The AirTAC SDA40X30-S-B-H is a double-acting single-rod compact cylinder engineered for tight axial spaces, delivering a push force of 628.3 N and a pull force of 527.8 N at 0.5 MPa. The riveted body assembly drastically reduces overall mounting length compared to conventional round-body units, making it highly effective for shrinking machine footprints. This specific configuration includes a male M14x1.5 piston rod thread for robust load coupling, an integrated magnet for position sensing, and fluororubber (FKM) seals for enhanced thermal and oil resistance.

Instead of an adjustable air cushion, the bore relies on a fixed NBR bumper at each end to decelerate the stroke. Because this bumper is not a lock or brake, high-speed applications should incorporate an external shock absorber. The built-in piston magnet interfaces with AirTAC reed or electronic switches fitted into the body grooves, while the hard-anodized inner wall ensures long service life.

Airtac SDA Ultra Thin Cylinder SDA40X30-S-B-H Technical Specifications

ModelAirtac SDA Ultra Thin Cylinder SDA40X30-S-B-H
SeriesSDA compact (thin) cylinder
Bore sizeØ40 mm
Stroke30 mm
Acting typeDouble acting
Port sizePT1/8
Rod end threadM8×1.25 female / M14×1.5 male (B)
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)
Max standard strokeUp to 120 mm

Specifications follow the official AirTAC SDA compact-cylinder datasheet. Confirm against the product label before installation. Port thread: PT (standard). Rod: female thread (blank) / male thread (B).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SDA Ultra Thin Cylinder SDA40X30-S-B-H

SDACompact (thin) double-acting cylinder series.
40Bore size in mm.
×30Stroke length in mm.
SBuilt-in magnet for magnetic-switch position sensing (omit = no magnet).
BMale-thread piston rod (omit = female-thread rod).

Thread: PT standard. Related SDA-family variants: SSA (single-acting push), STA (single-acting pull), SDAD (double rod), SDAJ (adjustable stroke), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDA Ultra Thin Cylinder SDA40X30-S-B-H Is Used

packaging

Carton Erector Flaps

Drives the folding mechanism on continuous motion packaging lines, utilizing the 30mm stroke and male rod end to push corrugated cardboard flaps into position for sealing.

precision_manufacturing

CNC Lathe Door Slide

Actuates the sliding safety door on a CNC turning center, where the short riveted body saves axial depth and the FKM seals withstand elevated ambient temperatures and coolant mist.

conveyor_belt

Bottle Divert Gate

Pivots a diverting arm on a bottling conveyor to sort containers, relying on the 628.3 N push force to overcome guide friction while a reed or electronic switch confirms the gate position.

Is the Airtac SDA Ultra Thin Cylinder SDA40X30-S-B-H the Right Cylinder?

When sizing this 40mm bore unit, evaluate your force margins carefully. Stepping down to the SDA32 yields 402.1 N of push force at 0.5 MPa, whereas stepping up to the SDA50 provides 981.7 N. Be aware that a standard compact cylinder will drift and cannot hold a load if air pressure drops or the valve is centered; maintaining vertical loads requires an external rod lock or a pilot-operated check valve. Confirm your ordering essentials: 40mm bore, 30mm stroke, PT1/8 port, male M14x1.5 rod, FKM seals, and a magnetic piston.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Short-body depth vs. a round-body cylinder
  • ✓ Port/thread type (PT)
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
  • ✓ Side load — avoid on a compact rod
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the short piston rod.
  • check Very long strokes are unsuitable for the compact body.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDA Ultra Thin Cylinder SDA40X30-S-B-H FAQ

This 40mm bore double-acting cylinder generates 628.3 N of push force and 527.8 N of pull force at 0.5 MPa. At 0.7 MPa, the push increases to 879.6 N. The theoretical maximum push is 128 kgf at 1.0 MPa. It operates between 0.15 and 1.0 MPa, with a proof pressure of 1.5 MPa, and runs at speeds from 30 to 500 mm/s.

It uses a fixed NBR bumper at each end to decelerate the piston near the stroke limits; this is not an adjustable air cushion. For high kinetic energy loads, you should add an external shock absorber. Additionally, the bumper is not a brake, so the cylinder cannot hold a load if air is lost or the valve is centered—you will need a pilot-operated check valve or external rod lock for position holding.
