AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10 is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke10 mm
  • Adjustable range0–10 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$24.62 $32.12Save 23% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10

The AirTAC SDAJ12X10-10 is a compact double-acting double-rod cylinder featuring an external M5x0.8 adjuster screw that lets you dial the extend stop from 0 to 10 mm directly on the machine.

Its short riveted body drastically reduces axial mounting depth where round-body or profile cylinders cannot fit. End-of-travel shock is handled by a fixed NBR bumper that decelerates the piston, which is not an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot support reed or electronic sensing.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10 Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke10 mm
Adjustable range0 – 10 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×10Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10 Is Used

science

Lab Automation Probes

Fine-tune sensor probe descent in tight analytical instruments where the short riveted body saves critical axial space and prevents over-travel damage.

view_module

Light Parts Ejection

Adjust the ejection stroke on the fly for small plastic or light metal parts, ensuring the 6 mm rod ejects gently using the fixed NBR bumper.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10 the Right Cylinder?

When sizing this 12 mm bore actuator, consider the adjacent SDAJ16, which raises the 0.5 MPa push output to 100.5 N for heavier resistance.

This model is specified for technicians who require on-site stroke tuning during frequent changeovers rather than machining new spacers. Confirm your parameters: 12 mm bore, 10 mm maximum stroke, 10 mm adjustment window, M5x0.8 port, female M3x0.5 rod-end thread, and no magnet. Remember that a plain cylinder does not hold position if air pressure drops; install an external rod lock or pilot-operated check valve for secure load holding.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–10 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10 FAQ

It operates between 0.15 and 1.0 MPa, runs at 30-500 mm/s, and functions in temperatures from -20 to +70 C.

Turning the M5x0.8 R screw shortens the extend stop by up to 10 mm, giving a usable extend range of 0 to 10 mm without changing the force output. This screw is strictly a mechanical stop, not a mid-stroke lock; the cylinder cannot hold a load on air loss, and the fixed NBR bumper only decelerates the stroke end.
