AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke10 mm
  • Adjustable range0–10 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$24.62 $32.12Save 23% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B

The AirTAC SDAJ12X10-10B is a compact double-acting cylinder with a male-thread piston rod and an external extend stop. An M5x0.8 adjuster screw lets you dial the extend position from 0 to 10 mm directly on the machine, eliminating the need for shims or part swaps during setup.

This 12 mm bore actuator features a short riveted body that saves axial mounting depth where round-body or profile cylinders will not fit. End-of-travel shock is handled by a fixed NBR bumper rather than an adjustable air cushion. Note this SKU lacks a piston magnet, so it cannot accept reed or electronic switches.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke10 mm
Adjustable range0 – 10 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×10Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B Is Used

precision_manufacturing

Micro-Clamp Dial-In

Dial the extend stop from 0 to 10 mm on the fly to set exact clamping depth for delicate electronic components without swapping shims.

build

Tight-Fixture Actuation

Fit the short riveted body into densely packed assembly fixtures where axial depth is restricted, using the male M5x0.8 rod for easy tooling attachment.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B the Right Cylinder?

When sizing this unit, consider the SDAJ16 as the next step up, which raises the push force to 100.5 N at 0.5 MPa; there is no smaller bore in the SDA family. Choose this specific male-rod (M5x0.8) configuration when you need external threading for mounting tooling, and confirm your requirements for the 10 mm stroke, 10 mm window, M5x0.8 port, and absence of a magnet.

On-machine stroke tuning is ideal for trial positioning and frequent changeovers. Keep in mind a plain cylinder does not hold its load on air loss or valve centring, as the piston drifts and the fixed bumper only decelerates near the end. For a held load without live pressure, install an external rod lock or a pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–10 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B FAQ

At 0.7 MPa, the push force is 79.2 N. The theoretical maximum push force is 12 kgf at 1.0 MPa.

The M5x0.8 adjuster screw mechanically shortens the extend stop by up to 10 mm, giving a usable extend range of 0 to 10 mm; it does not alter the force. This SKU lacks a magnet for sensors, and the cylinder cannot hold a load on air loss, so an external rod lock is needed for holding.

verified

Authorized Export Seller

Genuine AirTAC parts produced by AirTAC factory.

workspace_premium

1-Year Warranty

Covers non-human-caused product damage.

local_shipping

Fast Dispatch

Standard models are processed and dispatched in 3-5 business days.

bolt

Fast Reply

Most inquiries answered within 7-8 hours.

Related AirTAC SDAJ Cylinders

Request a Quote for Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10B

Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.

Thank you. We received your request for SDAJ12X10-10B and will confirm price, stock and lead time — usually within 7-8 hours.

For the fastest response, keep the complete model number above and include a clear photo of the product label. If photo upload is unavailable, email photos to [email protected] with your model number.
