AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10S

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10S is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke10 mm
  • Adjustable range0–10 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$28.34 $35.84Save 20% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10S

The AirTAC SDAJ12X10-10S is a compact double-acting double-rod cylinder featuring an on-site extend stop. A front M5x0.8 adjuster screw lets you dial the extend position anywhere from 0 to 10 mm without swapping parts.

This thin riveted-body design saves valuable axial mounting depth where larger profile cylinders cannot fit. The unit includes a built-in piston magnet for AirTAC reed or electronic switches, while fixed NBR bumpers decelerate the piston at the stroke extremes. Operating speed spans 30-500 mm/s across a 0.15-1.0 MPa pressure range.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10S Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10S
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke10 mm
Adjustable range0 – 10 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10S

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×10Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
