AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10 is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 5 to 15 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke15 mm
  • Adjustable range5–15 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$25.35 $32.85Save 22% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10

The AirTAC SDAJ12X15-10 is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. An M5x0.8 adjuster screw lets you dial the forward end-position anywhere between 5 and 15 mm directly on the machine, eliminating the need for shims or part swaps during changeovers. Retract travel remains full length.

The short riveted body saves axial mounting depth where round-body or profile cylinders will not fit. End shock is handled by a fixed NBR bumper, which decelerates the stroke but is not an adjustable air cushion.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10 Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke15 mm
Adjustable range5 – 15 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×15Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10 Is Used

precision_manufacturing

Micro-Clamp Tuning

Dial the extend stop from 5 to 15 mm to set exact clamping depth on delicate electronic components without machining new spacers.

view_module

Small Part Ejection

Fine-tune the pusher stroke on a compact assembly line to accommodate slight variations in miniature product heights.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10 the Right Cylinder?

This specific SKU lacks a piston magnet, so it cannot accept reed or electronic switches; choose the -S variant if sensing is required.

Confirm your parameters: 12 mm bore, 15 mm maximum stroke, 10 mm adjust window, M5x0.8 port, female rod-end thread, and no magnet. Note that a plain cylinder does not hold its load on air loss or valve centring; the piston drifts and the bumper only decelerates near the end. For a held load, specify an external rod lock or a pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 5–15 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10 FAQ

At 0.7 MPa, push is 79.2 N and pull is 59.4 N. The theoretical maximum push is 12 kgf at 1.0 MPa.

The M5x0.8 screw shortens the extend stop by up to 10 mm, giving a usable range of 5 to 15 mm. It is a mechanical stop, not a mid-stroke lock; the cylinder cannot hold a load without live air pressure.
