AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 5 to 15 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke15 mm
  • Adjustable range5–15 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$25.35 $32.85Save 22% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B

The AirTAC SDAJ12X15-10B is a compact double-acting double-rod cylinder featuring an on-site extend stop. By turning the external M5x0.8 adjuster screw, you set the outward stroke anywhere between 5 and 15 mm without changing parts.

This variant uses a male M5x0.8 piston rod thread and a 6 mm rod diameter. The short riveted body minimizes axial mounting depth where larger profile cylinders fail to fit. End shock is managed by a fixed NBR bumper, meaning there is no adjustable air cushion.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke15 mm
Adjustable range5 – 15 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×15Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B Is Used

precision_manufacturing

Micro-Clamp Dial-In

Perfect for small machining fixtures needing exact 5-15 mm clamp depth tuning on the machine without swapping shims.

science

Lab Probe Positioning

Ideal for testing rigs where the extend stop must be dialed precisely to touch a sample, avoiding overshoot in tight rigs.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B the Right Cylinder?

Stepping up to an SDAJ16 provides 100.5 N at 0.5 MPa if your force requirements exceed this capacity. This specific SKU includes the -B male rod thread but lacks the -S magnet, so position sensing is unavailable here.

The 10 mm adjustment window is excellent for trial positioning and frequent changeovers. Remember that a plain cylinder drifts when air is lost or a valve centers; the fixed bumper only decelerates near the end of travel. For load holding without live pressure, install an external rod lock or pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 5–15 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10B FAQ

At 0.5 MPa it pushes 56.5 N and pulls 42.4 N. At 0.7 MPa it pushes 79.2 N and pulls 59.4 N. The theoretical maximum push is 12 kgf at 1.0 MPa.

The M5x0.8 screw acts as a mechanical stop, allowing you to shorten the extend stroke from the 15 mm maximum down to 5 mm. It does not alter force or lock the piston mid-stroke.
