Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10S
$29.53
Regular price
$37.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ12X15-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The SDAJ12~25 Adjustable Ultra-Thin Cylinder Series by AIRTAC
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
Installation note:
Maintain 0.5mm clearance between cylinder and guide rails. Use locking compound on mounting screws (max torque 1.2N·m). For vertical mounting, install air vent downward. Lubricate every 500km stroke with ISO VG32 turbine oil.
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X15-10S Adjustable Ultra-Slim Cylinder Specifications
- Model Series: SDAJ12~25 (12mm to 25mm bore sizes)
- Specific Model: SDAJ12X15-10S
- Bore Size: 12mm
- Stroke: 15mm (adjustable via built-in stroke limiter)
- Operating Pressure: 0.05-0.9 MPa
- Cushioning: Rubber buffer + adjustable stroke mechanism
- Temperature Range: -20℃ to 80℃
- Port Size: M5x0.8 (standard) with NPT1/8 adaptor option
- Mounting Type: 10S (fixed type foot mounting)
- Body Material: Anodized aluminum alloy
- Rod Material: Stainless steel (SUS304)
- Seal Material: Heat-resistant NBR
- Weight: 0.15kg ±5% (without accessories)
- Dimensions: 50mm(L) × 32mm(W) × 12mm(H) (compact section height)
- Stroke Tolerance: ±0.5mm
- Max Speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation available)
Ultra-flat cylinder (only 12mm height) with space-saving design for precision linear motion. Features dual-action operation with magnetic piston for sensor compatibility. The 360° adjustable stroke mechanism allows micro-positioning via hex wrench. Corrosion-resistant construction with IP54 protection rating.
Typical Applications:
- Semiconductor wafer handling robots
- PCB depaneling machine actuators
- Medical device clamping mechanisms
- Packaging machine stopper cylinders
- Automated test equipment positioners
Installation note:
Maintain 0.5mm clearance between cylinder and guide rails. Use locking compound on mounting screws (max torque 1.2N·m). For vertical mounting, install air vent downward. Lubricate every 500km stroke with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | SDAJ12X15-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
