The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20 is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 15 mm on the machine — no shims, no part change.
The AirTAC SDAJ12X15-20 is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. Turning the M5x0.8 adjuster screw lets you dial the outward stroke down from a 15 mm maximum to a zero endpoint directly on the machine, eliminating the need for shims or part swaps.
Built with a short riveted body, this unit saves axial mounting depth where round-body or profile cylinders will not fit. End-of-travel shock is handled by a fixed NBR bumper, which decelerates the piston near the endpoint but is not an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot host reed or electronic switches without upgrading to the -S variant.
| Model | Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø12 mm |
| Max stroke | 15 mm |
| Adjustable range | 0 – 15 mm |
| Adjuster thread (R) | M5×0.8 |
| Port size | M5×0.8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M3×0.5 F / M5×0.8 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 42 N | 42 N |
| 0.7 MPa | 59 N | — |
| Max (@1.0 MPa) | 9 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 12 | Bore size in mm. |
| ×15 | Maximum stroke length in mm. |
| -20 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Ideal for test fixtures needing exact tip placement, where the external screw adjusts the outward reach without swapping components.
Fits into tight assembly machinery to push light components, using the short riveted body to save axial depth in dense layouts.
When sizing this 12 mm bore actuator, consider the SDAJ16 as the next step up, which raises the 0.5 MPa push force to 100.5 N for heavier resistance. Downward from 12 mm there is no smaller standard SDAJ option, making this the most compact choice in the family. The 0-15 mm outward range suits trial positioning and frequent changeover lines, while the 6 mm rod and M5x0.8 port keep the physical envelope extremely small.
Keep in mind that a plain SDAJ does not hold position or load when air is lost or the valve is centred; the fixed bumper only decelerates near the end and the adjuster is a mechanical stop, not a lock. For load holding without live pressure, integrate an external rod lock or pilot-operated check valve. Confirm your required bore, 15 mm stroke, 20 mm window, M5x0.8 port, female rod thread, and magnet status before ordering.
Quick checklist
At 0.7 MPa, push is 79.2 N and pull is 59.4 N. The theoretical maximum push is 12 kgf at 1.0 MPa.
The M5x0.8 adjuster screw shortens the extend stop by up to 20 mm. Since the nominal maximum stroke is 15 mm, turning the screw lets you set the outward endpoint anywhere from 0 to 15 mm, while retract remains full. This SKU lacks a magnet, so it cannot support switches.
