AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 15 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke15 mm
  • Adjustable range0–15 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$25.35 $32.85Save 22% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B

The AirTAC SDAJ12X15-20B is a compact double-acting double-rod cylinder featuring an external M5x0.8 adjuster screw that dials the extend stop from 0 to 15 mm directly on your machine.

Its short riveted body drastically reduces axial mounting depth where round-body or larger profile units cannot fit. This specific SKU includes a male M5x0.8 piston rod thread (option B) and lacks a piston magnet, meaning magnetic sensing is not supported without the -S variant. End-of-stroke deceleration relies on a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke15 mm
Adjustable range0 – 15 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×15Maximum stroke length in mm.
-20Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B Is Used

precision_manufacturing

Micro-Clamp Dial-In

Perfect for small machining fixtures where the male M5x0.8 rod threads into a custom jaw, letting operators fine-tune the 0-15 mm extend stop to clamp delicate parts without crushing them.

science

Lab Automation Positioning

Ideal for compact lab rigs needing exact end-point positioning; the M5x0.8 adjuster screw allows researchers to set the extend stop precisely without swapping out physical shims.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B the Right Cylinder?

When sizing this 12 mm bore actuator, evaluate your neighbours: dropping down is not an option as this is the smallest available bore, while stepping up to the SDAJ16 increases your 0.5 MPa push force to 100.5 N.

Choose this specific configuration if your fixture requires on-site stroke tuning during frequent changeovers. Verify your parameters: 12 mm bore, 15 mm maximum stroke, 20 mm adjustment window, M5x0.8 air port, male M5x0.8 rod thread, and no magnet. Remember that a plain cylinder does not hold position on air loss or valve centring; the piston drifts and the fixed bumper only decelerates near the end. For load holding without live pressure, install an external rod lock or pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–15 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20B FAQ

It operates between 0.15 and 1.0 MPa, handles speeds of 30-500 mm/s, and functions in temperatures from -20 to +70 C.

Turning the external R (M5x0.8) screw mechanically shortens the extend end-position by up to 20 mm, allowing you to set the usable extend stroke anywhere from 0 to 15 mm on the machine. This screw functions strictly as a mechanical stop and does not alter the cylinder's force output or lock the piston mid-stroke.
