Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20S
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X15-20S Adjustable Slim Cylinder Specifications
- Series: SDAJ12~25 Ultra-Compact Series
- Bore size: 12mm (0.47")
- Stroke: 15mm (adjustable)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max thrust: 7.5kgf @ 0.6MPa (forward), 6.3kgf @ 0.6MPa (return)
- Buffer type: Adjustable pneumatic cushion
- Mounting style: Dual side-tapped mounting holes with M4 threads
- Port size: M5×0.8 (standard) / NPT1/8 optional
- Piston speed: 50–700mm/s
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Material: Aluminum alloy body, NBR seals, CR/VMQ optional
- Protection rating: IP67 (wipers included)
- Weight: 0.23kg (0.51lb)
- Dimensions: 66mm(L) × 22mm(W) × 28mm(H)
- Rod end: Female M4 thread (standard) / clevis kit optional
Industry's thinnest 12mm bore cylinder (22mm width profile) with patented stroke adjustment mechanism. Features dual-position sensor slots (M5 mounting) and corrosion-resistant anodizing. Maintenance-free operation up to 3,000km service life at standard conditions. Requires 40μm filtered air with ISO VG32 oil mist lubrication recommended.
- PCB handling robots requiring precision linear motion
- Semiconductor wafer processing equipment
- Compact packaging machine gripper mechanisms
- Medical device actuation systems
- Automated test fixture positioning
Installation tip:
For vertical mounting, maintain ≤0.1mm alignment tolerance. Use locknuts on adjustment screws after setting stroke length.
Avoid side loads exceeding 3N·m. Annual seal inspection recommended for high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SDAJ12X15-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
