AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10 is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 10 to 20 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke20 mm
  • Adjustable range10–20 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$26.27 $33.77Save 22% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10

The AirTAC SDAJ12X20-10 is a compact double-acting double-rod cylinder featuring an external M5x0.8 R-thread adjuster screw. This mechanism lets you dial the extend stop directly on the machine between 10 and 20 mm, eliminating the need for shims or part swaps during fine-tuning. Retract remains a full stroke.

The short riveted body minimizes axial mounting depth where round-body units will not fit, while a fixed NBR bumper decelerates the stroke end. This specific SKU lacks a piston magnet, so it cannot host reed or electronic switches.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10 Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke20 mm
Adjustable range10 – 20 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×20Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10 Is Used

precision_manufacturing

Micro-Clamp Dial-In

Dial the extend stop from 10 to 20 mm to set exact clamping depth on fragile electronic subassemblies without machining new spacers.

build

Compact Fixture Setup

Fit the short riveted body into tight axial spaces and use the M5x0.8 R screw to fine-tune the tooling contact point during initial fixture commissioning.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10 the Right Cylinder?

Choose this unit when trial positioning or frequent changeovers require on-site stroke tuning.

Confirm the 20 mm maximum stroke, 10 mm adjustment window, and M5x0.8 air port. This base model has a female M3x0.5 rod-end thread with no magnet (no -S code). Remember that a plain cylinder does not hold its load on air loss or valve centring; the fixed bumper only decelerates near the end. For a held load, specify an external rod lock or a pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 10–20 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10 FAQ

Operating pressure is 0.15-1.0 MPa, proof pressure is 1.5 MPa, and speed ranges from 30-500 mm/s.

Turning the external M5x0.8 R screw shortens the extend end-position by up to 10 mm, giving a usable extend range of 10 to 20 mm while retract stays full. This SKU has no piston magnet, so it cannot take a switch; you must specify the -S option to use AirTAC reed or electronic sensors.
