AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 10 to 20 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke20 mm
  • Adjustable range10–20 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$26.27 $33.77Save 22% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B

The AirTAC SDAJ12X20-10B is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. A front M5x0.8 adjuster screw lets you dial the extend position anywhere between 10 and 20 mm directly on the machine, eliminating the need for shims or part swaps.

This thin riveted-body design saves valuable axial mounting depth where larger profile cylinders cannot fit. It features a male M5x0.8 piston rod thread, a fixed NBR bumper at each end to decelerate the stroke, and operates at speeds from 30 to 500 mm/s. Note that this specific SKU lacks a piston magnet, so it cannot support magnetic sensing.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke20 mm
Adjustable range10 – 20 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×20Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B Is Used

view_module

Small Part Ejection

Fine-tune the ejection stroke on a compact riveted body to push lightweight parts clear without adding axial depth to the tooling.

science

Lab Fixture Tuning

Adjust the male M5 rod end position on the fly for experimental fixtures, finding the optimal travel before locking the stop.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B the Right Cylinder?

When sizing this 12 mm bore actuator, evaluate both neighbors. Choose this model when your fixture requires on-site stroke tuning within the 10 to 20 mm window.

Confirm your parameters: 12 mm bore, 20 mm maximum stroke, 10 mm adjustment window, M5x0.8 air port, and a male M5x0.8 rod thread. Remember that a plain cylinder does not hold its load on air loss or valve centering; the piston drifts and the fixed bumper only decelerates near the end. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 10–20 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10B FAQ

Operating pressure is 0.15 to 1.0 MPa, proof pressure is 1.5 MPa, and the speed range is 30 to 500 mm/s.

The front M5x0.8 screw acts as a mechanical stop, shortening the extend stroke by up to 10 mm (usable range 10 to 20 mm). It does not alter the force or lock the piston mid-stroke. This SKU lacks a piston magnet, so it cannot accept reed or electronic switches; for load holding on air loss, use an external rod lock.
