The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10S is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 10 to 20 mm on the machine — no shims, no part change.
The AirTAC SDAJ12X20-10S is a compact double-acting double-rod cylinder featuring an external extend stop. A front M5x0.8 adjuster screw lets you dial the outward stroke down from its 20 mm maximum to 10 mm directly on the machine, avoiding part swaps during setup.
The short riveted body saves valuable axial mounting depth where round-body or profile cylinders cannot fit. This unit includes a built-in piston magnet (-S) for AirTAC reed or electronic switches, and relies on a fixed NBR bumper to decelerate the stroke end rather than an adjustable air cushion.
| Model | Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø12 mm |
| Max stroke | 20 mm |
| Adjustable range | 10 – 20 mm |
| Adjuster thread (R) | M5×0.8 |
| Port size | M5×0.8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M3×0.5 F / M5×0.8 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 42 N | 42 N |
| 0.7 MPa | 59 N | — |
| Max (@1.0 MPa) | 9 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 12 | Bore size in mm. |
| ×20 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Adjust the extend endpoint on the fly during test rig changeovers, using the M5x0.8 adjuster to find the exact contact depth without swapping cylinders.
Set precise ejection lengths for varied miniature electronic modules, relying on the compact riveted body to fit within dense assembly machinery.
Since 12 mm is the smallest available SDAJ bore, there is no smaller downward option.
This model suits operators needing on-site stroke tuning for frequent changeovers. Confirm your specs: 12 mm bore, 20 mm maximum stroke, 10 mm adjustment window, M5x0.8 port, built-in magnet, and female M3x0.5 rod-end thread. Note that a plain cylinder does not hold a load on air loss or valve centering; the fixed bumper only decelerates near the end. For load holding without live pressure, install an external rod lock or pilot-operated check valve.
Quick checklist
The R (M5x0.8) screw shortens the extend stop from the 20 mm maximum down to 10 mm without changing the force. The -S option provides a built-in magnet for AirTAC reed or electronic solid-state switches.
