AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 20 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke20 mm
  • Adjustable range0–20 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$26.27 $33.77Save 22% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B

The AirTAC SDAJ12X20-20B is a compact double-acting double-rod cylinder built for tight spaces, featuring a male M5x0.8 piston rod and an external extend stop. A fixed NBR bumper decelerates the stroke end, while the M5x0.8 R adjuster screw lets you dial the extend position from 0 to 20 mm directly on the machine without swapping parts. This on-site tuning is ideal for trial positioning, and the short riveted body drastically cuts axial mounting depth compared to conventional round-body units.

Note this SKU lacks a piston magnet, so it cannot host reed or electronic switches.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke20 mm
Adjustable range0 – 20 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×20Maximum stroke length in mm.
-20Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B Is Used

precision_manufacturing

Micro-Clamp Dial-In

Perfect for small machining fixtures where the 0-20 mm R screw tunes the exact clamping reach against delicate parts without shims.

view_module

PCB Pin Insertion

Use the male M5 rod to attach custom tooling; dial the downward extend stop on the line to safely insert components without crushing.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B the Right Cylinder?

Choose this specific unit when your fixture requires on-site stroke tuning within the 0-20 mm window and a male-thread M5x0.8 rod end for direct mounting. Confirm your requirements for the M5x0.8 air port, the fixed NBR bumper, and the lack of a magnet.

Keep in mind that a plain cylinder does not hold its load on air loss or when the valve is centered, as the piston drifts and the bumper only decelerates near the stroke end rather than acting as a lock. For secure load holding without live pressure, integrate an external rod lock or a pilot-operated check valve into your pneumatic circuit.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–20 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20B FAQ

Turning the M5x0.8 R screw shortens the extend stroke by up to 20 mm, allowing usable end positions between 0 and 20 mm. The retract stroke remains full, and the screw acts purely as a mechanical stop, not a mid-stroke lock.
