AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 20 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke20 mm
  • Adjustable range0–20 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$29.53 $37.03Save 20% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H

The AirTAC SDAJ12X20-20H is a compact double-acting double-rod cylinder featuring an external M5x0.8 adjuster screw that dials the extend stop from 0 to 20 mm directly on your machine. The short riveted body drastically reduces axial mounting depth where round-body or profile cylinders cannot fit.

This specific SKU includes an -H fluororubber (FKM) seal variant for enhanced thermal and oil resistance. End-of-travel deceleration relies on a fixed NBR bumper, which is not an adjustable air cushion. Note that this configuration omits a piston magnet, meaning it cannot host reed or electronic switches without changing to an -S variant.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke20 mm
Adjustable range0 – 20 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×20Maximum stroke length in mm.
-20Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H Is Used

precision_manufacturing

Micro-Clamp Tuning

Dial the extend stop from 0 to 20 mm during initial tooling setup to perfect the clamping depth on delicate electronic components without machining new spacers.

science

Lab Dispense Heads

Leverage the FKM seals for chemical compatibility while making fine 0-20 mm positional adjustments to a fluid dispensing needle tip on a research bench.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H the Right Cylinder?

Conversely, the 12 mm bore is the smallest in the family, making it the default choice for extremely tight footprints.

Operators who require frequent changeovers or trial positioning will benefit from the on-site stroke tuning without shims or part swaps. Confirm your requirements for a 12 mm bore, 20 mm maximum stroke, 20 mm adjustment window, M5x0.8 port, female M3x0.5 rod thread, and FKM seals. Remember that a plain SDAJ does not hold position or load upon air loss; the fixed bumper only decelerates near the end, so integrate an external rod lock or pilot-operated check valve for load holding.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–20 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20H FAQ

The operating pressure range is 0.15-1.0 MPa, with a proof pressure of 1.5 MPa.

Turning the R (M5x0.8) screw shortens the extend endpoint by up to 20 mm, yielding a usable extend range of 0-20 mm while retract remains full stroke. This SKU lacks a piston magnet and cannot accept switches; adding the -S option provides a magnet for AirTAC reed or electronic sensors.
