AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 20 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke20 mm
  • Adjustable range0–20 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$30.20 $37.70Save 19% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S

The AirTAC SDAJ12X20-20S is a compact double-acting double-rod cylinder featuring an external M5x0.8 R-thread adjuster screw. This mechanism lets you dial the extend stop down to 0 mm right on the machine, providing a usable extend window of 0-20 mm without changing any parts.

Built with a short riveted body, this unit saves axial mounting depth where round-body or profile cylinders simply will not fit. It relies on a fixed NBR bumper at each end to decelerate the stroke end, meaning it is not an adjustable air cushion. Equipped with a built-in piston magnet, the unit supports AirTAC reed or electronic switches for precise position sensing in tight assemblies.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke20 mm
Adjustable range0 – 20 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×20Maximum stroke length in mm.
-20Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S Is Used

precision_manufacturing

Micro-Clamp Dial-In

Perfect for small machining fixtures where the 0-20 mm extend window allows operators to fine-tune clamping contact on delicate parts without machining custom spacers.

view_module

Compact Ejector Setup

Fits into tight electronic assembly modules where axial space is restricted, enabling technicians to set a precise ejection stroke of up to 20 mm during initial commissioning.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S the Right Cylinder?

When sizing this 12 mm bore actuator, evaluate your force requirements bidirectionally. Choose this specific model if your fixture requires on-site stroke tuning to dial in a precise end position.

Remember that a standard compact cylinder does not hold its load when air is lost or the directional valve is centered; the piston will drift. The fixed NBR bumper only decelerates motion near the end of the stroke and the R screw acts as a mechanical stop, neither functions as a lock or brake. For load holding without live pressure, you must integrate an external rod lock or a pilot-operated check valve. This configuration includes the S magnet option for sensing and uses a female M3x0.5 rod-end thread with an M5x0.8 port.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–20 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20S FAQ

The theoretical maximum push is 12 kgf at 1.0 MPa. It operates on air at 0.15-1.0 MPa with a speed range of 30-500 mm/s.

The M5x0.8 R-thread screw mechanically shortens the extend stop by up to 20 mm, giving a usable extend range of 0-20 mm; retract remains full stroke. The S option includes a built-in piston magnet for use with AirTAC reed or electronic switches, and the adjustment changes the stop position only, not the force.
