AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10 is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 15 to 25 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke25 mm
  • Adjustable range15–25 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$27.21 $34.71Save 21% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10

The AirTAC SDAJ12X25-10 is a compact double-acting double-rod cylinder featuring an external extend stop. An M5x0.8 adjuster screw lets you dial the outward stroke on the machine between 15 and 25 mm without changing parts.

Its short riveted body drastically cuts axial mounting depth where round-body alternatives will not fit. End-of-travel deceleration relies on a fixed NBR bumper rather than an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot support reed or electronic switches.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10 Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke25 mm
Adjustable range15 – 25 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×25Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10 Is Used

precision_manufacturing

Small Part Pinning

Dial the 15-25 mm extend stop to press delicate pins into electronics housings without crushing the components.

science

Lab Automation

Use the compact 12 mm body to fit tight test fixtures, adjusting the outward reach precisely for various sample sizes.

view_module

Pick-and-Place Tweezing

Set the exact extension needed for gripping lightweight plastic parts during frequent machine changeovers.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10 the Right Cylinder?

If your layout is tight, the 12 mm bore saves space, but stepping up to 16 mm provides double the force if needed. The M5x0.8 port and 6 mm rod are fixed by the bore. Confirm your required extend window falls within the 15-25 mm range. This SKU has no magnet (no -S code), and uses a female M3x0.5 rod-end thread.

Operators needing frequent on-machine stroke tuning for changeovers will benefit from the external R screw. Remember that a plain cylinder does not hold a load when air is lost or the valve is centred; the bumper only decelerates near the end. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 15–25 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10 FAQ

The theoretical maximum push is 12 kgf at 1.0 MPa.

Turning the M5x0.8 R screw shortens the extend stroke by up to 10 mm, giving a usable outward range of 15 to 25 mm. It acts purely as a mechanical stop and does not alter the cylinder's force.
