AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 15 to 25 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke25 mm
  • Adjustable range15–25 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$27.21 $34.71Save 21% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B

The AirTAC SDAJ12X25-10B is a compact double-acting double-rod cylinder built for tight spaces, featuring a male M5x0.8 piston rod thread. A short riveted body minimizes axial mounting depth where larger profile or round-body units fail to fit.

An external M5x0.8 R adjuster screw lets you dial the extend stop directly on the machine, shortening the stroke by up to 10 mm for a usable 15 to 25 mm range. The screw sets the mechanical stop position without altering the pneumatic area, so output force remains constant. End shock is absorbed by a fixed NBR bumper, which decelerates the piston near the end of travel rather than acting as an adjustable air cushion.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke25 mm
Adjustable range15 – 25 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×25Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B Is Used

precision_manufacturing

Micro-Clamp Dial-In

Fine-tune the 15-25 mm extend stop on delicate machining fixtures to prevent crushing fragile components during tooling changeovers.

view_module

Small Part Ejection

Adjust the male M5 rod extension on assembly lines to reliably push lightweight parts varying in size without reprogramming the motion controller.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B the Right Cylinder?

If your application requires less force, no smaller SDAJ bore exists, so you must look at reducing pressure. Choose this specific male-thread rod configuration when your tooling requires an external M5x0.8 mount.

Engineers needing frequent changeover or trial positioning benefit most from this on-site tuning capability. Remember that a plain SDAJ does not hold position or load when air is lost or the valve is centred; the fixed bumper only decelerates near the end of travel. For load holding without live pressure, integrate an external rod lock or a pilot-operated check valve. Confirm your requirements for the 25 mm maximum stroke, 10 mm adjust window, M5x0.8 port, and male rod thread.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 15–25 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10B FAQ

The theoretical maximum push is 12 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa, proof pressure is 1.5 MPa, and speed ranges from 30-500 mm/s.

The M5x0.8 R screw mechanically shortens the extend stop by up to 10 mm, giving a usable 15-25 mm range. It sets the end position without changing the force. This SKU lacks a piston magnet so it cannot take a magnetic switch. The cylinder does not hold load on air loss; use an external rod lock for that.
