The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10S is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 15 to 25 mm on the machine — no shims, no part change.
The AirTAC SDAJ12X25-10S is a compact double-acting double-rod cylinder featuring an external M5x0.8 R screw that dials the extend stop from 15 to 25 mm directly on your machine.
Its short riveted body drastically cuts axial mounting depth where round-body or larger profile units fail to fit. A fixed NBR bumper handles end-of-stroke deceleration, while the integrated piston magnet supports AirTAC reed or electronic solid-state switches for position sensing.
| Model | Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-10S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø12 mm |
| Max stroke | 25 mm |
| Adjustable range | 15 – 25 mm |
| Adjuster thread (R) | M5×0.8 |
| Port size | M5×0.8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M3×0.5 F / M5×0.8 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 42 N | 42 N |
| 0.7 MPa | 59 N | — |
| Max (@1.0 MPa) | 9 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 12 | Bore size in mm. |
| ×25 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial the 15-25 mm extend stop to tune the ejection probe distance on a crowded 12 mm bore assembly station without swapping shims.
Fit the short riveted body into tight test fixtures and use the -S magnet to trigger reed or electronic switches for cycle counting.
When sizing this 12 mm bore unit, consider the adjacent SDAJ16, which raises the 0.5 MPa push to 100.5 N for heavier resistance.
This specific configuration includes a built-in magnet (-S) for sensing, a female M3x0.5 rod-end thread, and an M5x0.8 air port. Remember that a plain cylinder drifts when air is lost or the valve centers; the fixed bumper only decelerates near the end and is not a lock. For secure load holding without live pressure, install an external rod lock or pilot-operated check valve.
Quick checklist
This 12 mm bore double-acting cylinder pushes 56.5 N and pulls 42.4 N at 0.5 MPa. At 0.7 MPa it pushes 79.2 N. The theoretical maximum push is 12 kgf at 1.0 MPa. The air port is M5x0.8.
Turning the M5x0.8 R screw shortens the extend stroke by up to 10 mm, yielding a usable 15 to 25 mm range. The -S option includes a piston magnet compatible with AirTAC reed or electronic solid-state switches.
