Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20
$27.21
Regular price
$34.71
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ12X25-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The SDAJ12~25 Adjustable Ultra-Thin Cylinder Series by AIRTAC
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
Installation tip:
Use precision alignment jigs during mounting - maximum allowable
lateral misalignment is 0.2mm. For adjustable stroke operation,
rotate cushion dial while applying 0.3-0.5MPa air pressure.
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X25-20 Adjustable Ultra-Thin Cylinder Specifications
- Model: SDAJ12X25-20 (SDAJ series 12-25mm bore)
- Type: Double-acting adjustable stroke ultra-compact cylinder
- Bore size: 12mm (standard series includes 12/16/20/25mm)
- Stroke: 25mm (adjustable via built-in stroke limiter)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (360° rotatable design)
- Mounting style: Basic type (optional foot/mid/rod-end mounts)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, NBR seals
- Protection rating: IP54 (standard dust/moisture resistance)
- Weight: 0.15kg (excluding accessories)
- Dimensions: 65mm(L) × 20mm(W) × 20mm(H)
Industry's thinnest profile cylinder (20mm height) with integrated stroke adjustment mechanism. Features a maintenance-free guide structure and corrosion-resistant anodized finish. The T-slot piston design ensures precise linear motion with ≤0.5mm lateral play. Requires ISO 8573-1 class 3 compressed air.
Ideal for:
- High-density automation cells (SMT machines, IC handlers)
- Medical device actuators requiring precise force control
- Packaging line gripper mechanisms with space constraints
- Cleanroom-compatible semiconductor manufacturing tools
- Food processing equipment needing washdown resistance
Installation tip:
Use precision alignment jigs during mounting - maximum allowable
lateral misalignment is 0.2mm. For adjustable stroke operation,
rotate cushion dial while applying 0.3-0.5MPa air pressure.
| Property | Property Value |
|---|---|
| sku | SDAJ12X25-20 |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
