AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 5 to 25 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke25 mm
  • Adjustable range5–25 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$27.21 $34.71Save 21% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B

The AirTAC SDAJ12X25-20B is a compact double-acting double-rod cylinder built for tight spaces, featuring a male M5x0.8 piston rod and a 20mm external adjustment window. By turning the R (M5x0.8) screw, you set the extend stop anywhere between 5 and 25 mm directly on the machine. This on-site tuning eliminates shims and part swaps during changeovers.

The short riveted body saves axial mounting depth where round-body or profile cylinders will not fit. End shock is handled by a fixed NBR bumper, which decelerates the stroke but is not an adjustable air cushion.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke25 mm
Adjustable range5 – 25 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×25Maximum stroke length in mm.
-20Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B Is Used

precision_manufacturing

Micro-Clamp Dial-In

Dial the extend stop from 5 to 25 mm to set exact clamping depth on small fixtures without machining new spacers.

view_module

Short-Depth Ejector

Fit the compact riveted body into tight assembly cells to eject small parts, tuning the 20 mm window to match varying product widths.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B the Right Cylinder?

The male M5x0.8 rod thread, M5x0.8 air port, and 5-25 mm adjustability must match your mounting and positioning requirements.

A plain SDAJ does not hold a load when air is lost or the valve is centred, as the piston drifts and the fixed bumper only decelerates near the end of travel. For secure load holding without live pressure, integrate an external rod lock or a pilot-operated check valve. This SKU lacks a piston magnet, so position sensing is unavailable unless you specify the -S variant for reed or electronic switches.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 5–25 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20B FAQ

Turning the external R (M5x0.8) screw mechanically shortens the extend end position from the 25 mm maximum down to 5 mm. Retract remains full stroke, and the screw acts as a stop, not a mid-stroke lock.

verified

Authorized Export Seller

Genuine AirTAC parts produced by AirTAC factory.

workspace_premium

1-Year Warranty

Covers non-human-caused product damage.

local_shipping

Fast Dispatch

Standard models are processed and dispatched in 3-5 business days.

bolt

Fast Reply

Most inquiries answered within 7-8 hours.
