AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 5 to 25 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke25 mm
  • Adjustable range5–25 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$31.60 $39.10Save 19% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S

The AirTAC SDAJ12X25-20S is a compact double-acting double-rod cylinder featuring an external M5x0.8 adjuster screw that lets you dial the extend stop anywhere between 5 and 25 mm directly on the machine. The short riveted body drastically reduces axial mounting depth, fitting into tight spaces where larger profile cylinders cannot.

This unit includes a built-in piston magnet for AirTAC reed or electronic switches and uses a fixed NBR bumper at each end to decelerate the stroke. Operating speed ranges from 30-500 mm/s. Note that the bumper absorbs end-shock but is not an adjustable air cushion, and the stop screw is not a mid-stroke lock.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke25 mm
Adjustable range5 – 25 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×25Maximum stroke length in mm.
-20Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S Is Used

precision_manufacturing

Micro-Clamp Positioning

Dial the extend stop from 5 to 25 mm to set exact clamping depth on delicate electronic components without swapping shims or actuators.

science

Lab Dispense Trials

Iteratively tune the piston extension during fluid dispensing tests to find the optimal nozzle distance before locking the M5x0.8 adjuster.

view_module

Small Part Ejection

Adjust the push-out distance on the fly for varying product sizes, relying on the fixed NBR bumper to absorb the end-of-stroke impact.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S the Right Cylinder?

When sizing this 12 mm bore actuator, consider the neighbouring SDAJ16, which raises the 0.5 MPa push force to 100.5 N if your payload demands more authority. Downgrading is not applicable as 12 mm is the smallest available SDAJ bore.

Choose this specific configuration when you need frequent on-machine stroke tuning during setup or changeovers. Confirm your parameters: 12 mm bore, 25 mm maximum stroke, 20 mm adjust window, M5x0.8 port, female M3x0.5 rod thread, and the -S magnet option. Remember that a plain cylinder does not hold its load on air loss or valve centring; for load holding without live pressure, install an external rod lock or pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 5–25 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20S FAQ

At 0.7 MPa, the push is 79.2 N. The theoretical maximum push force is 12 kgf at 1.0 MPa.

The external R (M5x0.8) screw shortens the extend stroke by up to 20 mm, giving a usable extend range of 5 to 25 mm; retract remains full. The -S suffix means it has a built-in piston magnet compatible with AirTAC reed or electronic solid-state switches.
