AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30

The AirTAC SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30 is a genuine double-acting COMPACT cylinder (Ø12mm bore) whose extend end-position is set by an external M5×0.8 adjustment screw. You can dial the stroke anywhere from 0 to 25 mm on the machine — no shims, no part change.

  • BoreØ12 mm
  • Max stroke25 mm
  • Adjustable range0–25 mm
  • Adjuster threadM5×0.8
  • Port sizeM5×0.8
  • CushionFixed NBR bumper (both ends)
$27.21 $34.71Save 21% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ12 stroke, mounting and version on one page All SDAJ12 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30

The AirTAC SDAJ12X25-30 is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. An M5x0.8 adjuster screw lets you dial the outward stroke from 0 to 25 mm directly on the machine, eliminating the need for shims or part swaps during commissioning. Retract remains full length.

The short riveted body minimizes axial mounting depth where larger profile or round-body units will not fit. End-of-travel deceleration is handled by a fixed NBR bumper, not an adjustable air cushion.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30 Technical Specifications

ModelAirtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ12 mm
Max stroke25 mm
Adjustable range0 – 25 mm
Adjuster thread (R)M5×0.8
Port sizeM5×0.8
Acting typeDouble acting
Rod end threadM3×0.5 F / M5×0.8 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 30 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø12mm)

PressurePush forcePull force
0.5 MPa42 N42 N
0.7 MPa59 N—
Max (@1.0 MPa)9 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30

SDAJCompact double-acting cylinder with adjustable stroke.
12Bore size in mm.
×25Maximum stroke length in mm.
-30Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30 Is Used

precision_manufacturing

Micro-Clamp Dial-In

Ideal for small machining fixtures where the outward stroke must be fine-tuned to 0-25 mm to clamp delicate components without crushing them.

science

Lab Test Positioning

Perfect for laboratory automation requiring exact probe placement, allowing operators to set the extend stop on the fly during experimental setups.

Is the Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30 the Right Cylinder?

Downward is not an option as 12 mm is the smallest available bore. This model suits operators needing frequent on-site stroke tuning for trial positioning. Confirm your required extend window of 0-25 mm, the M5x0.8 port, and the female M3x0.5 rod-end thread. Note that this SKU lacks a piston magnet, so it cannot accept reed or electronic switches. For load holding without live pressure, install an external rod lock or pilot-operated check valve, as the fixed bumper only decelerates and never locks the piston.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–25 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M5×0.8 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-30 FAQ

An external M5x0.8 R screw acts as a mechanical stop, allowing you to shorten the extend position anywhere from 0 to 25 mm. It does not alter the output force, and the cylinder lacks a magnet for sensing.

verified

Authorized Export Seller

Genuine AirTAC parts produced by AirTAC factory.

workspace_premium

1-Year Warranty

Covers non-human-caused product damage.

local_shipping

Fast Dispatch

Standard models are processed and dispatched in 3-5 business days.

bolt

Fast Reply

Most inquiries answered within 7-8 hours.
