Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100S
2、Features riveted connection between cylinder body/rear cap and piston/piston rod for enhanced structural integrity;
3、Precision roller burnishing followed by hard anodizing treatment on inner bore surface ensures superior wear resistance and durability;
4、Unique custom bi-directional sealing profile with integrated oil reservoir optimizes compactness and lubrication retention;
5、Space-saving design minimizes installation footprint while maintaining performance;
6、Integrated sensor grooves along cylinder periphery facilitate effortless sensor mounting;
7、Available in multiple mounting configurations for flexible system integration.
Category: Slim Cylinders , Brand: AirTAC , Series: SDAJ32~40 Adjustable Ultra-Compact Cylinders
AirTAC SDAJ32X100-100S Adjustable Compact Cylinder Specifications
- Series: SDAJ32~40 Ultra-Slim Series
- Model: SDAJ32X100-100S
- Bore size: 32mm
- Stroke: 100mm (adjustable ±1mm via external screw)
- Operation type: Double-acting
- Working pressure: 0.05–0.9 MPa
- Port size: M5×0.8 (standard), optional NPT1/8
- Cushioning: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Mounting type: Basic foot mounting (ISO 15552 optional)
- Protection rating: IP54 (standard), IP67 available
- Weight: 680g ±3% (without accessories)
- Dimensions:
- Length: 196mm (fully retracted)
- Width: 48mm (body width)
- Height: 32mm (body height)
- Rod end thread: M10×1.25
Ultra-slim profile cylinder (only 32mm height) with precision stroke adjustment capability, designed for space-constrained automation systems. Features corrosion-resistant construction and smooth stroke control through optimized air flow channels. Includes magnetic piston for position sensing compatibility (sensor not included). Requires ISO 8573-1 class 3 or cleaner compressed air.
- PCB handling robots in electronics assembly
- Medical device positioning mechanisms
- Packaging machine clamping units
- Automated optical inspection (AOI) equipment
- Semiconductor wafer transfer systems
Installation note:
Maintain horizontal mounting for optimal performance. Lubricate with ISO VG32 turbine oil
every 500km of cumulative stroke. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | SDAJ32X100-100S |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
