AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB

The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 0 to 100 mm on the machine — no shims, no part change.

  • BoreØ32 mm
  • Max stroke100 mm
  • Adjustable range0–100 mm
  • Adjuster threadM10×1.25
  • Port sizePT1/8
  • CushionFixed NBR bumper (both ends)
$72.55 $80.05Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ32 stroke, mounting and version on one page All SDAJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB

The AirTAC SDAJ32X100-100SB is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the R (M10x1.25) screw, you can dial the extend position anywhere from 0 to 100 mm directly on the machine, while the retract stroke remains full.

This variant includes a built-in piston magnet for AirTAC reed or electronic switches and a male M10x1.25 piston rod end. The short riveted body saves axial mounting depth where a larger profile cylinder will not fit. End shock is handled by a fixed NBR bumper that decelerates the stroke, which is not an adjustable air cushion.

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB Technical Specifications

ModelAirtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ32 mm
Max stroke100 mm
Adjustable range0 – 100 mm
Adjuster thread (R)M10×1.25
Port sizePT1/8
Acting typeDouble acting
Rod end threadM6×1.0 F / M10×1.25 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 100 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa346 N346 N
0.7 MPa484 N—
Max (@1.0 MPa)70 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB

SDAJCompact double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Maximum stroke length in mm.
-100Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB Is Used

straighten

Adjustable Push Fixtures

Dial the extend stop from 0 to 100 mm to accommodate varying part widths without swapping cylinders on the fixture plate.

science

Trial Positioning Rigs

Set exact extend endpoints during prototype testing, relying on the fixed NBR bumper to absorb the impact of each test cycle.

Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB the Right Cylinder?

When sizing this 32 mm bore, evaluate both neighboring options.

Choose this unit if your fixture requires frequent changeovers or trial positioning across the full 0-100 mm window. It operates at 30-500 mm/s with a PT1/8 port. Remember that a plain cylinder does not hold its load on air loss or valve centering; the piston drifts and the bumper only decelerates near the end. For a held load, specify an external rod lock or a pilot-operated check valve. This specific SKU includes the -S magnet and -B male rod thread.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M10×1.25 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100SB FAQ

The theoretical maximum push is 82 kgf at 1.0 MPa.

The R (M10x1.25) screw shortens the extend stroke by up to 100 mm without changing the force. The included -S magnet works with AirTAC reed or electronic switches for position sensing.
