Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B
The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 90 to 100 mm on the machine — no shims, no part change.
- BoreØ32 mm
- Max stroke100 mm
- Adjustable range90–100 mm
- Adjuster threadM10×1.25
- Port sizePT1/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B
The AirTAC SDAJ32X100-10B is a double-acting compact cylinder featuring a 32mm bore and an external extend stop. A built-in M10x1.25 adjuster screw lets you dial the forward stroke down from the 100mm maximum to 90mm directly on the machine, eliminating the need for shims or part swaps during changeovers. The short riveted body saves axial mounting depth where round-body or profile cylinders will not fit.
This SKU uses a male M10x1.25 piston rod thread and lacks a piston magnet, meaning it cannot host reed or electronic switches. End shock is managed solely by a fixed NBR bumper, which decelerates the stroke end but is not an adjustable air cushion.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B Technical Specifications
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 90 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B Is Used
Tooling Setup Optimization
Dial in the 90-100mm extend stop via the M10x1.25 screw during initial tooling commissioning to perfect part contact without machining custom spacers.
Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B the Right Cylinder?
When sizing this 32mm bore, evaluate your force requirements against its neighbours.
This configuration is ideal for setups requiring on-site stroke tuning within the 90-100mm window. Note that a plain SDAJ does not hold a load if air pressure drops or the valve is centered; the piston drifts and the fixed bumper only decelerates near the end of travel. For secure load holding without live pressure, integrate an external rod lock or a pilot-operated check valve. Confirm your bore, 100mm stroke, 10mm adjust window, PT1/8 port, and male M10x1.25 rod thread before ordering.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 90–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M10×1.25 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10B FAQ
The external adjuster does not alter these force values.
Turning the R (M10x1.25) screw mechanically shortens the extend endpoint by up to 10mm, giving a usable forward range of 90-100mm. This SKU lacks a piston magnet, so it cannot support sensing switches; choose the -S variant if reed or electronic sensors are required.
