The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10S is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 90 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ32X100-10S is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the M10x1.25 adjuster screw, you can dial the extend position anywhere between 90 and 100 mm directly on the machine.
Its short riveted body saves valuable axial mounting depth where larger profile or round-body units will not fit. End-of-stroke energy is managed by a fixed NBR bumper that decelerates the piston, though it is not an adjustable air cushion. This unit includes a built-in piston magnet for AirTAC reed or electronic switches.
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 90 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Adjust the mechanical stop on the fly for varying package depths, relying on the fixed NBR bumper to absorb the end-of-stroke shock without needing an adjustable air cushion.
Choose this specific model when you need on-site stroke tuning to perfect a 90 to 100 mm extend position.
Confirm the bore, 100 mm maximum stroke, 10 mm adjustment window, and PT1/8 port. This variant includes the S magnet for sensing and a female M6x1.0 rod-end thread. Note that a plain cylinder does not hold a load if air pressure drops or the valve centers; the fixed bumper only decelerates near the end of travel. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve.
AirtacDistr lists every SDAJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj32-adjustable-cylinder
Quick checklist
The R (M10x1.25) screw shortens the extend stop by up to 10 mm, giving a usable 90-100 mm range without changing force. The included S magnet works with AirTAC reed or electronic solid-state switches for position sensing.
