The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10SB is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 90 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ32X100-10SB is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. A front R (M10x1.25) screw lets you dial the outward stroke down on-site across a 90 to 100 mm window, removing the need for shims or part swaps during machine commissioning.
This variant includes a built-in piston magnet (-S) for direct mounting of AirTAC reed or electronic switches along the body grooves, plus a male-threaded M10x1.25 piston rod (-B) for secure tooling attachment. The short riveted body saves valuable axial mounting depth where space is tight. End-of-travel deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion.
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-10SB |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 90 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial in the exact 90 to 100 mm contact depth on machining fixtures using the M10x1.25 adjuster screw without disassembling the cylinder body.
Choose this specific model if your fixture requires precise 90 to 100 mm outward positioning tweaks during changeovers.
Confirm the 32 mm bore, 100 mm maximum stroke, and 10 mm adjust window suit your cycle. The body uses a PT1/8 air port. This configuration includes the -S magnet for sensing and the -B male M10x1.25 rod end. Note that a plain compact cylinder does not hold a load if air pressure drops or the valve centres; the piston will drift. For suspended or vertical loads, integrate an external rod lock or a pilot-operated check valve.
Quick checklist
At 0.7 MPa the push is 563 N and pull is 483.8 N. The theoretical maximum push is 82 kgf at 1.0 MPa.
Turning the external R (M10x1.25) screw shortens the extend stroke within a 90 to 100 mm range without altering the output force. The included -S magnet allows you to track piston position using AirTAC reed or electronic switches mounted in the body grooves.
