Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20
The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20 is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 80 to 100 mm on the machine — no shims, no part change.
- BoreØ32 mm
- Max stroke100 mm
- Adjustable range80–100 mm
- Adjuster threadM10×1.25
- Port sizePT1/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20
The AirTAC SDAJ32X100-20 is a double-acting compact cylinder featuring an external R (M10x1.25) adjustment screw that dials the extend stop from 80 to 100 mm on-site.
Its short riveted body saves axial mounting depth where a larger profile cylinder will not fit. End-of-travel deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot host reed or electronic switches without upgrading to the -S variant.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20 Technical Specifications
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 80 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -20 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20 Is Used
Tooling Changeover
Dial the extend stop from 80 to 100 mm via the M10x1.25 screw during fixture swaps, hitting exact push positions without machining new spacers.
Prototype Positioning
Iterate the extend endpoint safely during R&D testing; the fixed NBR bumper absorbs end-shock while you find the optimal 80-100 mm travel.
Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20 the Right Cylinder?
Choose this unit if your application requires frequent on-machine stroke tuning between 80 and 100 mm without changing parts. Confirm your setup needs a PT1/8 port, a female M6x1.0 rod-end thread, and a 12 mm rod. Remember that a plain SDAJ does not hold position on air loss; for load holding without live pressure, install an external rod lock or pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 80–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M10×1.25 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20 FAQ
Turning the external R (M10x1.25) screw mechanically shortens the extend stroke by up to 20 mm, giving a usable 80-100 mm range. This SKU has no piston magnet; to use reed or electronic switches you must select the -S magnet option.
