Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B
The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 80 to 100 mm on the machine — no shims, no part change.
- BoreØ32 mm
- Max stroke100 mm
- Adjustable range80–100 mm
- Adjuster threadM10×1.25
- Port sizePT1/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B
The AirTAC SDAJ32X100-20B is a double-acting compact cylinder featuring an external R (M10x1.25) adjuster screw that lets you dial the extend stop down from 100 mm to 80 mm directly on the machine. This thin riveted-body design saves valuable axial mounting depth where round-body or profile cylinders cannot fit, and it accommodates standard AirTAC compact-cylinder accessories.
This specific SKU is configured with a male-thread piston rod (M10x1.25) and lacks a piston magnet, meaning it cannot accept reed or electronic switches without switching to the -S variant. End-of-stroke deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion. Operating speed spans 30-500 mm/s across a 0.15-1.0 MPa pressure range.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B Technical Specifications
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 80 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -20 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B Is Used
Package Diverters
Adjust the male M10x1.25 rod extension on-site to handle varying carton widths on the line, safely moving loads up to the 241 N safe working limit.
Vertical Lift Stops
Set exact raise heights for 20.5 kg payloads using the mechanical stop, relying on the fixed NBR bumper to absorb end-of-stroke shock in tight riveted-body envelopes.
Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B the Right Cylinder?
Choose this 100 mm stroke unit with the 20 mm adjustable window if your application requires frequent on-site stroke tuning during changeovers.
Confirm the bore (32 mm), maximum stroke (100 mm), 20 mm adjustment window, and PT1/8 air port match your pneumatic layout. This SKU specifies the -B male M10x1.25 rod end and no magnet (no -S code). Note that a plain SDAJ does not hold position or load when air is lost or the valve is centred; the fixed bumper only decelerates near the end of travel. For load holding without live pressure, integrate an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 80–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M10×1.25 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20B FAQ
The air port is PT1/8.
The external R (M10x1.25) screw mechanically shortens the extend end-position from 100 mm down to 80 mm without changing the force output. This specific SKU lacks a piston magnet, so it cannot accept reed or electronic switches; you must select the -S variant for sensing capabilities.
