The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20S is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 80 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ32X100-20S is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. Turning the R (M10x1.25) screw lets you dial the forward end-position anywhere between 80 and 100 mm directly on the machine, eliminating the need for shims or part swaps during changeover. Retract remains full length.
This thin riveted-body design saves axial mounting depth where round-body or profile cylinders will not fit. The unit includes a built-in piston magnet (-S) for AirTAC reed or electronic switches, operating at speeds from 30 to 500 mm/s. End-of-travel deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion.
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 80 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -20 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial the R screw to vary the extend stop between 80 and 100 mm, perfectly setting the clamp depth for different raw casting widths on a single fixture.
Adjust the mechanical stop on-site to fold varying box heights, relying on the fixed NBR bumper to absorb the end-of-stroke shock safely.
Choose this specific model if your fixture requires frequent on-site stroke tuning across an 80 to 100 mm window.
Confirm your parameters: 32 mm bore, 100 mm max stroke, 20 mm adjust window, PT1/8 port, and a female M6x1.0 rod-end thread. The included -S magnet enables position sensing. Remember that a plain cylinder does not hold a load if air pressure drops or the valve centers; the piston drifts. For load holding without live pressure, install an external rod lock or a pilot-operated check valve.
AirtacDistr lists every SDAJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj32-adjustable-cylinder
Quick checklist
The external M10x1.25 screw shortens the extend stroke by up to 20 mm, giving a usable range of 80 to 100 mm. The built-in -S magnet allows tracking by AirTAC reed or electronic switches.
