Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30
The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30 is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 70 to 100 mm on the machine — no shims, no part change.
- BoreØ32 mm
- Max stroke100 mm
- Adjustable range70–100 mm
- Adjuster threadM10×1.25
- Port sizePT1/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30
The AirTAC SDAJ32X100-30 is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the R (M10x1.25) screw, you shorten the forward stroke on-site, dialling the rod end precisely between 70 and 100 mm without changing parts.
Its short riveted body saves valuable axial mounting depth where round-body or profile cylinders will not fit. End-of-travel deceleration relies on a fixed NBR bumper rather than an adjustable air cushion. This specific SKU lacks a piston magnet, so it cannot host reed or electronic switches; choose the -S variant if you require position sensing.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30 Technical Specifications
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 70 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 30 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -30 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30 Is Used
Tooling Changeover
Dial the extend stop from 70 to 100 mm during machine retrofitting to hit new datum points without machining replacement spacers.
Press Fit Calibration
Safely trial positioning for delicate bearing insertion by limiting the forward travel, relying on the fixed NBR bumper for end deceleration.
Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30 the Right Cylinder?
Choose this unit if your fixture requires frequent on-machine stroke tuning across a 70-100 mm window.
Confirm your parameters: 32 mm bore, 100 mm maximum stroke, 30 mm adjuster window, PT1/8 port, female M6x1.0 rod thread, and no magnet. Remember that a plain SDAJ does not hold position or load when air is lost or the valve is centred; the fixed bumper only decelerates near the end. For secure load holding without live pressure, integrate an external rod lock or pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 70–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M10×1.25 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30 FAQ
It operates between 0.15 and 1.0 MPa at speeds of 30-500 mm/s.
The M10x1.25 adjuster screw mechanically limits the extend stroke between 70 and 100 mm; it does not alter force. The cylinder cannot hold a load on air loss, as the fixed NBR bumper only decelerates the stroke end rather than locking it.
