AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB

The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 70 to 100 mm on the machine — no shims, no part change.

  • BoreØ32 mm
  • Max stroke100 mm
  • Adjustable range70–100 mm
  • Adjuster threadM10×1.25
  • Port sizePT1/8
  • CushionFixed NBR bumper (both ends)
$72.55 $80.05Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ32 stroke, mounting and version on one page All SDAJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB

The AirTAC SDAJ32X100-30SB is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. Turning the R (M10x1.25) screw lets you dial the outward stroke down on-site from 100 mm to 70 mm without swapping shims or parts.

This variant includes a built-in piston magnet (-S) for AirTAC reed or electronic switches and a male-thread piston rod (-B, M10x1.25) for secure tool mounting. The short riveted body saves axial mounting depth where round-body or profile units will not fit. End shock is absorbed by a fixed NBR bumper that decelerates the stroke end but is not an adjustable air cushion or a mid-stroke lock.

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB Technical Specifications

ModelAirtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ32 mm
Max stroke100 mm
Adjustable range70 – 100 mm
Adjuster thread (R)M10×1.25
Port sizePT1/8
Acting typeDouble acting
Rod end threadM6×1.0 F / M10×1.25 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 30 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa346 N346 N
0.7 MPa484 N—
Max (@1.0 MPa)70 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB

SDAJCompact double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Maximum stroke length in mm.
-30Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB Is Used

precision_manufacturing

Machining Clamp Tuning

Dial the extend stop from 70 to 100 mm to secure varied fixture widths on a single machining centre without machining custom spacers.

straighten

Bending Stop Block

Set a precise mechanical end-position for sheet metal bending tools, relying on the male M10x1.25 rod thread to mount hardened contact tips.

Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB the Right Cylinder?

Choose it when you need on-site stroke tuning during frequent changeovers.

Confirm the 100 mm maximum stroke, 30 mm adjust window, and PT1/8 port. The -S magnet enables position sensing, while the -B option supplies the male M10x1.25 rod end. Remember that a plain cylinder drifts on air loss or valve centring; the fixed bumper only decelerates near the end. For load holding without live pressure, install an external rod lock or pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 70–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M10×1.25 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30SB FAQ

The theoretical maximum push is 82 kgf at 1.0 MPa.

The R (M10x1.25) screw shortens the extend end-position anywhere between 70 and 100 mm; retract remains full. The -S code means a built-in magnet is installed for AirTAC reed or electronic switches.
